CS6220: DATA MINING TECHNIQUES

Instructor: Yizhou Sun

yzsun@ccs.neu.edu January 19, 2016

Matrix Data: Prediction

Announcements

• Team formation due next Wednesday
• Homework 1 out by tomorrow

2

Today’s Schedule

• Course Project Introduction
• Linear Regression Model
• Decision Tree

3

Methods to Learn

Matrix Data Text Data Set Data Sequence Data Time Series Graph & Network Images Classification

Decision Tree; Naïve Bayes; Logistic Regression SVM; kNN HMM Label Propagation Neural Network

Clustering

K-means; hierarchical clustering; DBSCAN; Mixture Models; kernel k- means* PLSA SCAN; Spectral Clustering

Frequent Pattern Mining

Apriori; FP-growth GSP; PrefixSpan

Prediction

Linear Regression Autoregression Collaborative Filtering

Similarity Search

DTW P-PageRank

Ranking

PageRank 4

How to learn these algorithms?

• Three levels
• When it is applicable?
• Input, output, strengths, weaknesses, time

complexity

• How it works?
• Pseudo-code, work flows, major steps
• Can work out a toy problem by pen and paper
• Why it works?
• Intuition, philosophy, objective, derivation, proof

5

Matrix Data: Prediction

• Matrix Data
• Linear Regression Model
• Model Evaluation and Selection
• Summary

6

Example

7

                  np x ... nf x ... n1 x ... ... ... ... ... ip x ... if x ... i1 x ... ... ... ... ... 1p x ... 1f x ... 11 x

A matrix of n × 𝑞:

• n data objects / points
• p attributes / dimensions

Attribute Type

• Numerical
• E.g., height, income
• Categorical / discrete
• E.g., Sex, Race

8

Categorical Attribute Types

• Nominal: categories, states, or “names of things”
• Hair_color = {auburn, black, blond, brown, grey, red, white}
• marital status, occupation, ID numbers, zip codes
• Binary
• Nominal attribute with only 2 states (0 and 1)
• Symmetric binary: both outcomes equally important
• e.g., gender
• Asymmetric binary: outcomes not equally important.
• e.g., medical test (positive vs. negative)
• Convention: assign 1 to most important outcome (e.g., HIV positive)
• Ordinal
• Values have a meaningful order (ranking) but magnitude between

successive values is not known.

• Size = {small, medium, large}, grades, army rankings

9

Matrix Data: Prediction

• Matrix Data
• Linear Regression Model
• Model Evaluation and Selection
• Summary

10

Linear Regression

• Ordinary Least Square Regression
• Closed form solution
• Gradient descent
• Linear Regression with Probabilistic

Interpretation

11

The Linear Regression Problem

• Any Attributes to Continuous Value: x ⇒ y
• {age; major ; gender; race} ⇒ GPA
• {income; credit score; profession} ⇒ loan
• {college; major ; GPA} ⇒ future income
• ...

12

Illustration

13

Formalization

• Data: n independent data objects
• 𝑧𝑗, i = 1, … , 𝑜
• 𝒚𝑗 = 𝑦𝑗0, 𝑦𝑗1, 𝑦𝑗2, … , 𝑦𝑗𝑞

T, i = 1, … , 𝑜

• A constant factor is added to model the bias

term, i. e. , 𝑦𝑗0 = 1

• Model:
• 𝑧: dependent variable
• 𝒚: explanatory variables
• 𝜸 = 𝛾0, 𝛾1, … , 𝛾𝑞

𝑈: 𝑥𝑓𝑗𝑕ℎ𝑢 𝑤𝑓𝑑𝑢𝑝𝑠

• 𝑧 = 𝒚𝑈𝜸 = 𝛾0 + 𝑦1𝛾1 + 𝑦2𝛾2 + ⋯ + 𝑦𝑞𝛾𝑞

14

A 2-step Process

• Model Construction
• Use training data to find the best parameter 𝜸,

, denoted as 𝜸

• Model Usage
• Model Evaluation
• Use validation data to select the best model
• Feature selection
• Apply the model to the unseen data (test data):

𝑧 = 𝒚𝑈 𝜸

15

Least Square Estimation

• Cost function (Total Square Error):
• 𝐾 𝜸 = 𝑗 𝒚𝑗

𝑈𝜸 − 𝑧𝑗 2

• Matrix form:
• 𝐾 𝜸 = X𝜸 − 𝒛 𝑈(𝑌𝜸 − 𝒛)
• r X𝜸 − 𝒛

2

16

𝒀: 𝒐 × 𝒒 + 𝟐 matrix

                  np x ... nf x ... n1 x ... ... ... ... ... ip x ... if x ... i1 x ... ... ... ... ... 1p x ... 1f x ... 11 x , 1 , 1 , 1

𝑧1 ⋮ 𝑧𝑗 ⋮ 𝑧𝑜 y: 𝒐 × 𝟐 𝐰𝐟𝐝𝐮𝐩𝐬

Ordinary Least Squares (OLS)

• Goal: find

𝜸 that minimizes 𝐾 𝜸

• 𝐾 𝜸 = X𝜸 − 𝑧 𝑈 𝑌𝜸 − 𝑧

= 𝜸𝑈𝑌𝑈𝑌𝜸 − 𝑧𝑈𝑌𝜸 − 𝜸𝑈𝑌𝑈𝑧 + 𝑧𝑈𝑧

• Ordinary least squares
• Set first derivative of 𝐾 𝜸 as 0
• 𝜖𝐾

𝜖𝜸 = 2𝜸𝑈XTX − 2𝑧𝑈𝑌 = 0

• ⇒

𝜸 = 𝑌𝑈𝑌

−1𝑌𝑈𝑧

17

Gradient Descent

• Minimize the cost function by moving

down in the steepest direction

18

Batch Gradient Descent

• Move in the direction of steepest descend

Repeat until converge { }

19

𝜸(𝑢+1):=𝜸(t) − 𝜃

𝜖𝐾 𝜖𝜸 𝜸=𝜸(t) ,

Where 𝐾 𝜸 = 𝑗 𝒚𝑗

𝑈𝜸 − 𝑧𝑗 2 = 𝑗 𝐾𝑗(𝜸) and

𝜖𝐾 𝜖𝜸 =

𝑗

𝜖𝐾𝑗 𝜖𝜸 =

𝑗

2𝒚𝑗 (𝒚𝑗

𝑈𝜸 − 𝑧𝑗) e.g., 𝜃 = 0.1

Stochastic Gradient Descent

• When a new observation, i, comes in, update

weight immediately (extremely useful for large- scale datasets):

Repeat { for i=1:n {

𝜸(𝑢+1):=𝜸(t) + 2𝜃(𝑧𝑗 − 𝒚𝑗

𝑈𝜸(𝑢))𝒚𝑗

} }

20

If the prediction for object i is smaller than the real value, 𝜸 should move forward to the direction of 𝒚𝑗

Other Practical Issues

• What if 𝑌𝑈𝑌 is not invertible?
• Add a small portion of identity matrix, λ𝐽, to it

(ridge regression* )

• What if some attributes are categorical?
• Set dummy variables
• E.g., 𝑦 = 1, 𝑗𝑔 𝑡𝑓𝑦 = 𝐺; 𝑦 = 0, 𝑗𝑔 𝑡𝑓𝑦 = 𝑁
• Nominal variable with multiple values?
• Create more dummy variables for one variable
• What if non-linear correlation exists?
• Transform features, say, 𝑦 to 𝑦2

21

Probabilistic Interpretation

• Review of normal distribution
• X~𝑂 𝜈, 𝜏2 ⇒ 𝑔 𝑌 = 𝑦 =

1 2𝜌𝜏2 𝑓− 𝑦−𝜈 2

2𝜏2

22

Probabilistic Interpretation

• Model: 𝑧𝑗 = 𝑦𝑗

𝑈𝛾 + ε𝑗

• ε𝑗~𝑂(0, 𝜏2)
• 𝑧𝑗 𝑦𝑗, 𝛾~𝑂(𝑦𝑗

𝑈𝛾, 𝜏2)

• 𝐹 𝑧𝑗 𝑦𝑗 = 𝑦𝑗

𝑈𝛾

• Likelihood:
• 𝑀 𝜸 = 𝑗 𝑞 𝑧𝑗 𝑦𝑗, 𝛾)

= 𝑗

1 2𝜌𝜏2 exp{− 𝑧𝑗−𝒚𝑗

𝑈𝜸 2

2𝜏2

}

• Maximum Likelihood Estimation
• find

𝜸 that maximizes L 𝜸

• arg max 𝑀 = arg min 𝐾, Equivalent to OLS!

23

Matrix Data: Prediction

• Matrix Data
• Linear Regression Model
• Model Evaluation and Selection
• Summary

24

Model Selection Problem

• Basic problem:
• how to choose between competing linear regression

models

• Model too simple:
• “underfit” the data; poor predictions; high bias; low

variance

• Model too complex:
• “overfit” the data; poor predictions; low bias; high

variance

• Model just right:
• balance bias and variance to get good predictions

25

Bias and Variance

• Bias: 𝐹(

𝑔 𝑦 ) − 𝑔(𝑦)

• How far away is the expectation of the estimator to the true

value? The smaller the better.

• Variance: 𝑊𝑏𝑠

𝑔 𝑦 = 𝐹[ 𝑔 𝑦 − 𝐹 𝑔 𝑦

2

]

• How variant is the estimator? The smaller the better.
• Reconsider mean square error
• 𝐾

𝜸 /𝑜 = 𝑗 𝒚𝑗

𝑈

𝜸 − 𝑧𝑗

2/𝑜

• Can be considered as
• 𝐹[

𝑔 𝑦 − 𝑔(𝑦) − 𝜁

2] = 𝑐𝑗𝑏𝑡2 + 𝑤𝑏𝑠𝑗𝑏𝑜𝑑𝑓 + 𝑜𝑝𝑗𝑡𝑓

26

Note 𝐹 𝜁 = 0, 𝑊𝑏𝑠 𝜁 = 𝜏2

True predictor 𝑔 𝑦 : 𝑦𝑈𝜸 Estimated predictor 𝑔 𝑦 : 𝑦𝑈 𝜸

Bias-Variance Trade-off

27

Cross-Validation

• Partition the data into K folds
• Use K-1 fold as training, and 1 fold as testing
• Calculate the average accuracy best on K

training-testing pairs

• Accuracy on validation/test dataset!
• Mean square error can again be used: 𝑗 𝒚𝑗

𝑈

𝜸 − 𝑧𝑗

2/𝑜

28

AIC & BIC*

• AIC and BIC can be used to test the quality
• f statistical models
• AIC (Aka

kaike ike information formation criterion erion)

• 𝐵𝐽𝐷 = 2𝑙 − 2ln(

𝑀),

• where k is the number of parameters in the model

and 𝑀 is the likelihood under the estimated parameter

• BIC (Bayesian Information criterion)
• B𝐽𝐷 = 𝑙𝑚𝑜(𝑜) − 2ln(

𝑀),

• Where n is the number of objects

29

Stepwise Feature Selection

• Avoid brute-force selection
• 2𝑞
• Forward selection
• Starting with the best single feature
• Always add the feature that improves the performance

best

• Stop if no feature will further improve the performance
• Backward elimination
• Start with the full model
• Always remove the feature that results in the best

performance enhancement

• Stop if removing any feature will get worse performance

30

Matrix Data: Prediction

• Matrix Data
• Linear Regression Model
• Model Evaluation and Selection
• Summary

31

Summary

• What is matrix data?
• Attribute types
• Linear regression
• OLS
• Probabilistic interpretation
• Model Evaluation and Selection
• Bias-Variance Trade-off
• Mean square error
• Cross-validation, AIC, BIC, step-wise feature

selection

32
