CS140 Lecture 09a: Brief History of Computing

1

John Magee

17 February 2017

Some images courtesy Wikimedia Commons, IBM, DEC

"There is no reason anyone would want a computer in their home."

• - Ken Olson, founder and CEO of Digital Equipment Corp., 1977

Overview/Questions

– Where did computers come from? – When were computers first discovered? – Why should you care about the history of computing?

2

Early History of Computing

3

Abacus (2400 BC) Ancient device to record numeric values Above: a reconstructed Roman abacus

Early History of Computing

4

Blaise Pascal (1623-1662) Mechanical device to add, subtract, divide & multiply

Early History of Computing

5

Joseph Jacquard (1801) Jacquard’s Loom, the punched card

Programmability

6

3

What tricks does your computer do?

– Web browsing, email, instant messenger – Play games – Watch movies, organize photos – Word processing, spreadsheets, database

Programmability is the ability to give a general- purpose computer instructions so that it can perform new tasks.

Difference Engine

Charles Babages’ mechanical calculating machine, designed in 1820s.

http://www.youtube.com/watch?v= B8tmfcOg8l8 http://www.youtube.com/watch?v= 0anIyVGeWOI Ada Lovelace: First Algorithm

7

Finite State Machines

– AKA Finite State Automata – Think about a Traffic light operation

• There are only a limited number of “states” –

configurations of lights.

• Each state transitions into a new state.
• E.g. Green  Yellow  Red

8

Turing Machines

Alan Turing

• Considered to be the father of Computer Science
• Also known for the “Turing Test” for Artificial

Intelligence

Turing Machine - 1936

• A turing machine is an abstract thought

experiment.

• Mathematical proof of computability of algorithm.
• Basis for Computer Science Theory.

9

Early Digital Computers

10

Harvard Mark I (1944)

Harvard Mark I

11

IBM Archives

Early Digital Computers

12

Harvard Mark I (1944) First fully automatic digital computer to be completed

• 51 feet wide, 8 feet high, 2 feet deep
• Built out of switches, relays, and rotating

mechanical shafts/clutches

• Storage for 72 numbers, each 23 decimal digits

in length

• Read instructions from paper tape, one at a time

Early Digital Computers

13

ENIAC (1946)

Electronic Numerical Integrator And Computer

• first general-purpose electronic computer
• 80 feet wide, 8.5 feet high, 3 feet deep
• No moving parts
• Ability to conditional branch – do the next operation based
• n the result of the previous operation.
• 17,468 vacuum tubes, 7,200 crystal diodes, 1,500 relays,

70,000 resistors, 10,000 capacitors and around 5 million hand-soldered joints.

• 5,000 Hz, 324 multiplications/second

ENIAC

14

First Computer Bug

15

Log of first computer bug, discovered by Grace Hopper, 1945 A Computer Science Pioneer, she later wrote the first Compiler.

16

The earliest digital computers were programmed by wiring them up to perform some specific logic. Pictured: Harvard Mark I

Computer Programming, 0.X

17

Computer Programming, 0.X

Later, instructions were programmed by flipping switches. Pictured: Digital Equipment PDP-8

Demo:

http://www.youtube.com/watch?v= DPioENtAHuY

18

Stored Program Computer

John von Neumann

(a mathematician who worked on the atomic bomb)

– Described a computer architecture in which instructions are read from the memory space (RAM), just like data. – This design enables programmability, by making it relatively easy to provide new instructions to the computer’s hardware.

19

Stored Program Computer (Von Neumann Architecture)

Figure 5.1 The von Neumann architecture

Architecture

 Harvard Architecture:

– Instructions separate from data.

 Von Neumann Architecture:

– Instructions = data. – All stored in the same memory. – A program can write a program! (Compilers) – All modern computers based on this.

20

21

Stored Program Computer

Data and instructions to manipulate the data are logically the same (binary code) and can be stored in the same place (RAM). The machine language of a particular computer is the set of binary coded instructions built into its hardware.

22

Machine Language

Characteristics of machine language:

– Every processor type has its own set

• f specific machine instructions.

– The relationship between the processor type and the instructions it can carry out is completely integrated. – Each machine-language instruction does only

• ne very low-level task.

Mainframes

23

Univac 1108 (1964) IBM 704 (1954)

First floating point hardware mass produced

1960’s-1970’s

 Interactive sessions  Multi-user systems – Time-sharing – Terminals  “mini”computers

24

DEC PDP-7

Grace Hopper

1944: One of the first programmers of Harvard Mark I. 1949: Suggested programming with English words. 1952: First compiler: “Nobody believed that," she

• said. "I had a running compiler and nobody would

touch it. They told me computers could only do arithmetic.” 1959 – 1977: COBOL programming language. 1986: Retired as oldest active-duty commissioned

• fficer in the US navy.

25

Grace Hopper

1989: Honorary Degree at Clark University. 2016: Presidential Medal of Freedom 2017: Yale announced plan to rename one of its undergraduate colleges Grace Murray Hopper College.

Annual Convention: The Grace Hopper Celebration of Women in Computing

26

Margaret Hamilton

Lead Apollo flight software designer. Hamilton has published over 130 papers, proceedings, and reports about the 60 projects and six major programs in which she has been involved. Legitimized the use of the term "software

engineering“ as a disciplined approach to

science and engineering of software. CEO of two software companies she founded. 2016 Presidential Medal of Freedom

27

Rise of the PC

PBS Series hosted by Bob Cringely https://vimeo.com/124201377 9:24 - Cringely explains digital computing, program, 10:00 - data, instructions in binary, flipping switches, etc. Grace Hopper, programming COBOL, mainframe computers, punch cards, Wozniak, Jobs on programming, 12:58 - microprocessor (vacuum tubes, transistors, chips ), Intel 15:30 - Altair 8800 19:20 - Homebrew computer club 20:30 - Mellon/Garland @ computer club, binary addition by flipping switches 22:30 - programming language/basic interpreter, Paul Allen, Bill Gates // 27:00

28

Video: Triumph of the Nerds

Rise of the PC

PBS Series hosted by Bob Cringely 27:00 - Microsoft in Albuquerque, basic for the Altair 29:12 - Steve Jobs, Jim Warren, sixties counter culture 31:30 - Apple Computer, Apple I, II // 35:00 35:00 - venture capital for apple, apple II, manufacture 37:10 - computer fair 40:00 - Intro VisiCalc on an Apple II 44:38 - wall street use of PC 46:15 - wrap up characters 48:50 - closing remarks

29

Video: Triumph of the Nerds

Rise of the PC (1979 --)

What happened next?

– IBM PC and Microsoft

• Disk Operating System (DOS)

– Apple, Amiga, Tandy, Atari, IBM… – IBM “Clones” / PC Compatibles – … the Internet… to be continued… – What is a “killer app”? – What’s next?

30

What happened to women in CS?

Right: Elsie Shutt founded one of the first software businesses in the U.S. in 1958. And the programmers were all women. NPR: “When Women Stopped Coding”

http://www.npr.org/sections/money/2016/07/22/487069271/episode-576-when-women-stopped-coding http://www.npr.org/sections/money/2014/10/21/357629765/when-women-stopped-coding “And these toys were marketed almost entirely to men and boys.” 31

Moore’s Law

32

Early Personal Computers

Computer Ads:

http://blogs.pcworld.com/techlog/archives/002950.html  Atari 400 (1980) http://www.youtube.com/watch?v= 5sr28fygmOQ

 Commodore VI C-20 (1981)

http://www.youtube.com/watch?v= gVX5cyMOGAk

 Compaq portable computer

http://www.youtube.com/watch?v= YTMdXZ_QwTo

33
