CS 61A Discussion 5

Trees, Mutation, Box and Pointers, Nonlocal

Attendance: links.cs61a.org/albert-disc Slides: albertxu.xyz/teaching/cs61a/

Albert Xu

Announcements

An anatomical perspective

Trees

1 2 3 4 5 6 7 8 9

Root Leaves Branch Labels Nodes

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

which of these, if any, is a tree?

What is a Tree?

1 2 3 4 5 6 7 8 9

Credit: From Jerry Chen, and based on Prof. DeNero's tree diagram [Fa 16 CS 61A]

• A tree consists of a label, along with a list of branches,

each of which are themselves trees.

• This is a recursive definition, can you see why?
• Leaves are trees too! They just don’t have any branches
• f their own.

Trees - Designing an ADT

2 4 5

• A tree consists of a label, along with a list of branches,

each of which are themselves trees.

• This is a recursive definition, can you see why?
• Leaves are trees too! They just don’t have any branches
• f their own.

Trees - Designing an ADT

2 4 5

Label

• A tree consists of a label, along with a list of branches,

each of which are themselves trees.

• This is a recursive definition, can you see why?
• Leaves are trees too! They just don’t have any branches
• f their own.

Trees - Designing an ADT

2 4 5

Label branch 0

• A tree consists of a label, along with a list of branches,

each of which are themselves trees.

• This is a recursive definition, can you see why?
• Leaves are trees too! They just don’t have any branches
• f their own.

Trees - Designing an ADT

2 4 5

Label branch 0 branch 1

• A tree consists of a label, along with a list of branches,

each of which are themselves trees.

• This is a recursive definition, can you see why?
• Leaves are trees too! They just don’t have any branches
• f their own.

Trees - Designing an ADT

2 4 5

Label branches[0] branches[1]

Trees - Designing an ADT

# Constructor def tree(label, branches=[]): for branch in branches: assert is_tree(branch) return [label] + list(branches) # Selectors def label(tree): return tree[0] def branches(tree): return tree[1:] def is_leaf(tree): return not branches(tree)

Box and Pointer Diagrams

how do you draw lists on environment diagrams?

Box and Pointer Diagrams

how do you draw lists on environment diagrams?

Box and Pointer Diagrams

how do you draw lists on environment diagrams?

Box and Pointer Diagrams

how do you draw lists on environment diagrams?

Box and Pointer Diagrams

how do you draw lists on environment diagrams?

Examining List Slicing

Remember list slicing?

<list>[<start>:<stop>] - returns the part of a list between <start>, inclusive, and <stop>, non-inclusive

Remember list slicing?

<list>[<start>:<stop>] - returns the part of a list between <start>, inclusive, and <stop>, non-inclusive

If I wrote this:

>>> a = [1,2,3] >>> b = a[2:]

Examining List Slicing

Remember list slicing?

<list>[<start>:<stop>] - returns the part of a list between <start>, inclusive, and <stop>, non-inclusive

If I wrote this:

>>> a = [1,2,3] >>> b = a[2:]

Question: b is the result of a list slice of a. Did this slice mutate a or create a new list?

Examining List Slicing

Remember list slicing?

<list>[<start>:<stop>] - returns the part of a list between <start>, inclusive, and <stop>, non-inclusive

If I wrote this:

>>> a = [1,2,3] >>> b = a[2:]

Question: b is the result of a list slice of a. Did this slice mutate a or create a new list?

it created a new list - we’re trying to slice out part

• f an old list, but we don’t want to be changing

that old list!

Examining List Slicing

List Mutation

the central question - does it mutate or create a new list?

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] -

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.
• lst = lst + lst2 -

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.
• lst = lst + lst2 - a new list. Adding two lists shouldn’t

change the originals, it should make a third(new) one!

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.
• lst = lst + lst2 - a new list. Adding two lists shouldn’t

change the originals, it should make a third(new) one!

• lst += lst2 -

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.
• lst = lst + lst2 - a new list. Adding two lists shouldn’t

change the originals, it should make a third(new) one!

• lst += lst2 - the same list. This is slightly different, and tricky!

This syntax implies that we’re trying to add a second list to the first

• ne, so Python just sticks it onto the end of the old list.

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.
• lst = lst + lst2 - a new list. Adding two lists shouldn’t

change the originals, it should make a third(new) one!

• lst += lst2 - the same list. This is slightly different, and tricky!

This syntax implies that we’re trying to add a second list to the first

• ne, so Python just sticks it onto the end of the old list.
• lst = list(lst) -

List Mutation

the central question - does it mutate or create a new list? For each of the following, decide whether it mutates or creates a new list, i.e. is lst the same or a new list?

• lst = lst[a:b] - a new list, as we said earlier.
• lst = lst + lst2 - a new list. Adding two lists shouldn’t

change the originals, it should make a third(new) one!

• lst += lst2 - the same list. This is slightly different, and tricky!

This syntax implies that we’re trying to add a second list to the first

• ne, so Python just sticks it onto the end of the old list.
• lst = list(lst) - a new list. This is specifically because list

takes whatever iterable is given and sticks each element into a new list, even if the original iterable was already a list.

Methods that Mutate

some more methods that add to a list

Methods that Mutate

some more methods that add to a list

• lst.append(elem)
• Adds elem to the end of lst
• Increases list length by ONE always

Methods that Mutate

some more methods that add to a list

• lst.append(elem)
• Adds elem to the end of lst
• Increases list length by ONE always
• lst.extend(seq)
• Adds elements in seq to the end of lst

Methods that Mutate

some more methods that add to a list

• lst.append(elem)
• Adds elem to the end of lst
• Increases list length by ONE always
• lst.extend(seq)
• Adds elements in seq to the end of lst
• lst.insert(i, elem)
• Inserts elem into lst at index i
• The rest of the elements get pushed rightwards

Methods that Mutate

some more methods that add to a list

• lst.append(elem)
• Adds elem to the end of lst
• Increases list length by ONE always
• lst.extend(seq)
• Adds elements in seq to the end of lst
• lst.insert(i, elem)
• Inserts elem into lst at index i
• The rest of the elements get pushed rightwards

*All of these return None!

Methods that Mutate

some more methods that remove from a list

Methods that Mutate

some more methods that remove from a list

• lst.remove(elem)
• Removes the first instance of elem in lst
• Throws ValueError if elem is not in lst
• Returns None

Methods that Mutate

some more methods that remove from a list

• lst.remove(elem)
• Removes the first instance of elem in lst
• Throws ValueError if elem is not in lst
• Returns None
• lst.pop()/lst.pop(i)
• In the first case, removes the last element of lst
• In the second case, removes the ith element from lst
• Returns the removed element!

Nonlocal

changing some of your programming paradigms

• remember how we said that each frame has its own set of variables?

Nonlocal

changing some of your programming paradigms

• remember how we said that each frame has its own set of variables?
• if a variable doesn’t exist in the current frame(say, f2), you can look

up its value from a parent frame(say, f1)

Nonlocal

changing some of your programming paradigms

• remember how we said that each frame has its own set of variables?
• if a variable doesn’t exist in the current frame(say, f2), you can look

up its value from a parent frame(say, f1)

• …but it’s impossible for you to change the value of that parent

frame’s(f1’s) variable from inside f2!

Nonlocal

changing some of your programming paradigms

• remember how we said that each frame has its own set of variables?
• if a variable doesn’t exist in the current frame(say, f2), you can look

up its value from a parent frame(say, f1)

• …but it’s impossible for you to change the value of that parent

frame’s(f1’s) variable from inside f2!

not anymore!

Nonlocal

changing some of your programming paradigms

• remember how we said that each frame has its own set of variables?
• if a variable doesn’t exist in the current frame(say, f2), you can look

up its value from a parent frame(say, f1)

• …but it’s impossible for you to change the value of that parent

frame’s(f1’s) variable from inside f2!

not anymore! nonlocal x

Nonlocal

changing some of your programming paradigms

• remember how we said that each frame has its own set of variables?
• if a variable doesn’t exist in the current frame(say, f2), you can look

up its value from a parent frame(say, f1)

• …but it’s impossible for you to change the value of that parent

frame’s(f1’s) variable from inside f2!

not anymore! nonlocal x

this line, when run inside f2, says that every time we modify x inside the current frame(f2), instead modify f1’s x! Same thing with looking up x.

Nonlocal Demo

demo!

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Exhibit A

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Exhibit A

attempting to nonlocal a variable that already exists in the current frame

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Exhibit A

I L L E G A L ! ! !

attempting to nonlocal a variable that already exists in the current frame

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Exhibit A Exhibit B

I L L E G A L ! ! !

attempting to nonlocal a variable that already exists in the current frame

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Exhibit A Exhibit B

attempting to nonlocal a variable from the global frame

I L L E G A L ! ! !

attempting to nonlocal a variable that already exists in the current frame

Pitfalls of Nonlocal

there are two common mistakes that students make with nonlocal, and it’s probably a good idea to learn them well

Exhibit A

attempting to nonlocal a variable that already exists in the current frame

Exhibit B

I L L E G A L ! ! ! ILLEGAL!!!

attempting to nonlocal a variable from the global frame

UnboundLocalError

this is probably a good time to talk about it

*i borrowed this incorrect code from StackOverflow lol

UnboundLocalError

this is probably a good time to talk about it here is code which throws an UnboundLocalError

*i borrowed this incorrect code from StackOverflow lol

UnboundLocalError

this is probably a good time to talk about it here is code which throws an UnboundLocalError

*i borrowed this incorrect code from StackOverflow lol

…which is equivalent to

UnboundLocalError

this is probably a good time to talk about it here is code which throws an UnboundLocalError

*i borrowed this incorrect code from StackOverflow lol

…which is equivalent to

Python has no variable declarations, so it has to guess the scope of your variables! Because you assigned a value of x inside the increment function, it assumes that x is a variable inside the increment frame. But by the order in which we evaluate the RHS of assignment before the left, we look up x before it even exists in the frame!

UnboundLocalError

this is probably a good time to talk about it here is code which throws an UnboundLocalError

*i borrowed this incorrect code from StackOverflow lol

…which is equivalent to

Python has no variable declarations, so it has to guess the scope of your variables! Because you assigned a value of x inside the increment function, it assumes that x is a variable inside the increment frame. But by the order in which we evaluate the RHS of assignment before the left, we look up x before it even exists in the frame!

this is an analysis of the issue, but it’s not the root cause. How could anonymous SO user easily fix this?

UnboundLocalError

this is probably a good time to talk about it here is code which throws an UnboundLocalError

*i borrowed this incorrect code from StackOverflow lol

…which is equivalent to

Python has no variable declarations, so it has to guess the scope of your variables! Because you assigned a value of x inside the increment function, it assumes that x is a variable inside the increment frame. But by the order in which we evaluate the RHS of assignment before the left, we look up x before it even exists in the frame!

this is an analysis of the issue, but it’s not the root cause. How could anonymous SO user easily fix this?

trick question!!

UnboundLocalError

this is probably a good time to talk about it code that errors.

*i borrowed this incorrect code from StackOverflow lol

UnboundLocalError

this is probably a good time to talk about it code that errors.

*i borrowed this incorrect code from StackOverflow lol

UnboundLocalError

this is probably a good time to talk about it code that errors.

*i borrowed this incorrect code from StackOverflow lol

Also errors!! remember? ILLEGAL!!!

UnboundLocalError

this is probably a good time to talk about it code that errors.

*i borrowed this incorrect code from StackOverflow lol

Also errors!! remember? ILLEGAL!!! this one works!

UnboundLocalError

this is probably a good time to talk about it code that errors.

*i borrowed this incorrect code from StackOverflow lol

Also errors!! remember? ILLEGAL!!! this one works! unfortunately you don’t necessarily learn the global keyword in this class, just fyi!

Thanks for coming.

Have a great rest of your week! :)

Attendance: links.cs61a.org/albert-disc Slides: albertxu.xyz/teaching/cs61a/
