Compiler Construction

Lecture 2: Compiler Structure and Lexical Analysis 2020-01-10 Michael Engel

Includes material by Jan Christian Meyer

Compiler Construction 02: Compiler Structure, Scanning

2

.org

Theoretical and practical exercises

• TA: Lahiru Rasnayake
• Six problem sets, one every two weeks
• Theoretical questions on scanning, parsing, optimization…
• Practical: build parts of your own small compiler (in C)
• Get your own software project running

• Solutions need to be handed in on time
• Rather, an empty solution than a plagiarized one
• Only the final two will be graded
• 20% of the final grade (80% exam)
• More details next week

Compiler Construction 02: Compiler Structure, Scanning

3

Overview

• Overview: definition and tasks of a compiler
• Structure and stages of a typical compiler
• Deterministic finite automata (DFA)
• Lexical analysis (scanning)

Compiler Construction 02: Compiler Structure, Scanning

4

Compilers are everywhere

• Original idea: enable programming of computers in higher-

level abstractions than machine language

– Zuse's Plankalkül (1940s), FORTAN, LISP, A0 (1950s)

• Today:

– Many different source languages and target platforms

• Additional uses of compilers:

– Static analysis and verification – Hardware synthesis – Source-to-source transformations – Just in time (JIT) compilation

Compiler Construction 02: Compiler Structure, Scanning

5

What does a compiler do?

• Compiler:


“Tool that translates software written in one language into another language”

• must understand both the form, or syntax, and content, or

meaning (semantics), of the input language

• and understand the rules that govern syntax and mean-

ing in the output language

• needs a scheme for mapping content from the source

language to the target language

• Requirements:
• must preserve the meaning of the program being compiled
• must improve the input program in some discernible way


Compiler Construction 02: Compiler Structure, Scanning

6

The compilation process black box

int factorial(int n) { int fact = 1; while (n--) fact = fact * n; return n; } . . . 0xE59F1010 0xE59F0008 0xE0815000 0xE59F5008 . . .

?

Compiler Construction 02: Compiler Structure, Scanning

7

Compilation process in detail

source code in
 high-level language (.c) preprocessor preprocessed code compiler assembler code (.s) assembler machine (“object”) code (.o) linker executable code loader debugger libraries

Compiler Construction 02: Compiler Structure, Scanning

8

Structure of a compiler (1)

“understand both the form,

• r syntax, and content, or

meaning (semantics), of the input language”

Frontend Backend Source code Target program

compiler “understand the rules that govern syntax and mean- ing in the output language” “scheme for mapping content from the source language to the target language”

Compiler Construction 02: Compiler Structure, Scanning

9

Structure of a compiler (2)

“understand both the form,

• r syntax, and content, or

meaning (semantics), of the input language”

Frontend Backend Source code Target program

compiler “understand the rules that govern syntax and mean- ing in the output language” “scheme for mapping content from the source language to the target language” “must improve the input program in some discernible way”

Optimizer IR IR

Compiler Construction 02: Compiler Structure, Scanning

10

Intermediate representation (IR)

• Early compilers directly


generated machine code

• n source languages, m targets:

n x m compilers required!

• Idea: use a common description


format:“Intermediate Representation” (IR) – Transform source to IR (front end) and IR to target code (back end):


• nly n + m compilers required now
• Additional advantages of using intermediate representations:

– Easy to change source or target language – Easier optimizations: developed only for the intermediate representation – Intermediate representation can be directly interpreted

Java ML Pascal C C++ Sparc MIPS Pentium Itanium Java ML Pascal C C++ Sparc MIPS Pentium Itanium IR

Compiler Construction 02: Compiler Structure, Scanning

11

Stages of a compiler (1)

Lexical analysis (scanning): – Split source code into lexical units – Recognize tokens (using regular expressions/automata) – Token: character sequence relevant to source language grammar



Lexical analysis Syntax analysis Semantic analysis Code generation Code

• ptimization

Source code character stream token sequence machine-level program x = y + 42 id(x)

• p(=)

id(y)

• p(+)

number(42) character stream token sequence

Compiler Construction 02: Compiler Structure, Scanning

12

Stages of a compiler (2)

Syntax analysis (parsing) – Uses grammar of the source language – Decides if input token sequence can be
 derived from the grammar


id(x)

• p(=)

id(y)

• p(+)

number(42) Lexical analysis Semantic analysis Code generation Code

• ptimization

Source code token sequence machine-level program Syntax analysis syntax tree

Compiler Construction 02: Compiler Structure, Scanning

13

Stages of a compiler (3)

Semantic analysis – Name analysis (check def. & scope of symbols) – Type analysis (check correct type of expressions) – Creation of symbol tables (map identifiers to their types and positions in the source code)

Syntax analysis Semantic analysis syntax tree IR Lexical analysis Code generation Code

• ptimization

Source code machine-level program

Compiler Construction 02: Compiler Structure, Scanning

14

Stages of a compiler (5)

Code optimization – Analyzes & applies patterns of redundancy – e.g., store of a variable followed by a load of it – Often, different stages/levels of optimization with different intermediate representations are applied

Code generation Code

• ptimization

IR Semantic analysis Syntax analysis Lexical analysis Source code machine-level program IR

Compiler Construction 02: Compiler Structure, Scanning

15

Stages of a compiler (4)

Code generation – Determines and outputs equivalent machine instructions
 for components of the IR (instruction selection) – Determines correct instruction order with respect to pipeline constraints,
 exploitation of instruction-level parallelism (instruction scheduling) – Assigns variables to registers (register allocation) and memory locations

Semantic analysis Code generation IR Syntax analysis Lexical analysis Code

• ptimization

Source code machine-level program machine code

Compiler Construction 02: Compiler Structure, Scanning

16

Lexical analysis (scanning)

• The compiler input is simply a stream (sequence) of bytes:



 72, 101, 108, 108, 111, 32, 119, 111, 114, 108, 100, ...


• By convention, these are mapped to letters, digits, etc.:



 ‘H’, ‘e’, ‘l’, ‘l’, ‘o’, ‘ ‘, ‘w’,’o’,’r’,’l’,’d’, ...

• Other mappings (encodings) exist
• e.g. Unicode UTF-8, EBCDIC
• On this level, the input program is just a lot of bytes without

any structure

Lexical analysis ASCII encoding

Compiler Construction 02: Compiler Structure, Scanning

17

Lexical analysis (scanning)

• Naive approach to scanning:


Read letters one by one, e.g., for a key word “while”:



 w (119), h (104), i (105), l (108), e (10)

• Writing a compiler that has to detect this pattern every time

the programmer wants to start a loop is inconvenient:

• A programmer might choose to call a variable 'whilf':



 w (119), h (104), i (105), l (108), (looking good so far…)
 f (10) (oh no, start from scratch, that’s not a loop)

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

18

Identifying syntactical units

• Better approach:


Group letters into meaningful units and operate on those:



 ‘i’, ‘f’, ‘(‘, ‘w’,’h’, ‘i’, ‘l’, ‘f’, ‘=’, ‘=’, ‘2’, ‘)’, ‘{‘, ‘x’, ‘=’, ‘5’, ‘;’, ‘}’

 if ( whilf == 2 ) { x = 5; }


• Here, we use color coding to identify the various units:

keywords and punctuation
 delimiters of groups
 variables


• perators


numbers

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

19

Deriving code structure

• What use is the coloring of our units?


We've already seen this one:


if ( whilf == 2 ) { x = 5; }



How would we color that line?


while ( a < 42 ) { a += 2; }

 Using the same coloring roles, we get:
 while ( a < 42 ) { a += 2; }

• These two statements have completely different meanings but share the

same (syntactic) structure (here: sequence of colors)

• We’ll talk about structure later
• Today, we will look at lexical analysis


Lexical analysis

keywords and punctuation
 delimiters of groups
 variables


• perators


numbers

Compiler Construction 02: Compiler Structure, Scanning

20

Useful definitions

• Lexeme
• Lexemes are units of lexical analysis, words
• They’re like entries in the dictionary, “house”, “walk”, “smooth”
• Token
• Tokens are units of syntactic analysis
• They are like units of a sentence, “noun”,“verb”,“adjective”
• Semantic
• The meaning of something (there is no sensible unit)
• Similar to explanations in the dictionary:
• house: “a building which someone inhabits”
• walk: “the act of putting one foot in front of the other”
• smooth: “the property of a surface which offers little resistance

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

21

Classes of lexemes

• Lexemes with a fixed meaning
• keywords or reserved words
• “if", “while”, “for”, “==“, …
• Most languages forbid the use of these as identifiers (variable/

function/… names)

• Source is easier to parse, less ambiguous code
• Classes with countably infinite instances
• e.g. 1, 2, 3, … 65535, …
• All of these are specific cases of the class “integer number"

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

22

Finite automata

• Required:


Mechanism to identify classes of words (not just single words)

• Example: mechanism to recognize real numbers
• Informal description:


“A real number starts with one or more digits optionally followed by a decimal point followed by zero or more digits”

• Formal approach: Deterministic Finite Automaton (DFA)
• example given as a directed graph here (easy to follow)

s1 s2 s3 [0-9] [0-9] '.' [0-9]

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

23

DFA structure

s1 s2 s3 Nodes (vertices V) = States
 (here: s1, s2, s3) States s2, s3 are
 accepting states (double outline) Automaton starts here Edges E = Transitions (annotated with conditions)

DFAs are often represented as directed graph G = (V, E)

[0-9] [0-9] '.' [0-9]

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

24

DFA formal definition

Formal definition: DFA = 5-tuple (Q, Σ, δ, q0, F) Q is a finite set called the states, Σ is a finite set called the alphabet, δ: Q×Σ → Q is the transition function, q0 ∈ Q is the start state, and F ⊆ Q is the set of accepting states

s1 s2 s3 [0-9] [0-9] '.' [0-9]

Q = {s1, s2, s3} Σ = {0,1,2,3,4,5,6,7,8,9,.} q0 = s1 F = {s2, s3} δ = ???

Lexical analysis

s2

Compiler Construction 02: Compiler Structure, Scanning

25

Transition function of a DFA

Give the subsequent state for each state and each possible input, commonly as a table:

δ

1 2 3 4 5 6 7 8 9 . s1 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 input character current state s1 s2 s3 [0-9] [0-9] '.' [0-9]

Lexical analysis

Q = {s1, s2, s3} Σ = {0,1,2,3,4,5,6,7,8,9,.} q0 = s1 F = {s2, s3} δ = ???

Compiler Construction 02: Compiler Structure, Scanning

26

Example DFA transition

s1 s2 s3 [0-9] [0-9] '.' [0-9]

δ

1 2 3 4 5 6 7 8 9 . s1 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 Input character sequence:

4 2 . 2 3

Read 1st char: '4' ➙ change to s2 Start: in state s1 Read 2nd char: '2' ➙ stay in s2 Read 3rd char: '.' ➙ change to s3 Read 4th char: '2' ➙ stay in s3 Read 5th char: '3' ➙ stay in s3 End of sequence in accepting state ✔

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

27

Error handling

• What happens when a character '.' is read in state s1 or s3?

δ

1 2 3 4 5 6 7 8 9 . s1 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 ??? s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 ??? s1 s2 s3 [0-9] [0-9] '.' [0-9] Error '.' '.'

The error state is

• ften omitted in DFA

descriptions. Implied: all non indicated characters ➙ error

Lexical analysis

Compiler Construction 02: Compiler Structure, Scanning

28

Implementing a DFA in C the hard way

enum {error = 0, success}; int scan_real_number(void) { char c; enum states = {s1, s2, s3}; enum states cur = s1; while (1) { c = getchar(); // get next char if (c==EOF) break; // end? switch(cur) { case s1:
 if (c>='0' && c<='9') cur = s2; else return error; break; case s2: if (c>='0' && c<='9') cur = s2; else if (c=='.')
 cur = s3; else return error; break;

s1 s2 s3 [0-9] [0-9] '.' [0-9] Error '.' '.'

case s3: if (c>='0' && c<='9') cur = s3; else return error; break; } // switch } // while // check for accepting state if (cur != s2 && cur != s3) return error; else return success; }

Compiler Construction 02: Compiler Structure, Scanning

29

Implementing a table-driven DFA in C

enum {error = 0, success}; enum states {s1, s2, s3, er}; enum states cur = s1; char alphabet[] = { '0', '1', '2', '3', '4',
 '5', '6', '7', '8', '9', '.' }; // next state for each char in alphabet (columns) struct scanner { enum states next[sizeof(alphabet)];
 }; // rows of the transition table struct scanner delta[sizeof(enum states)] = { // 0 1 2 3 4 5 6 7 8 9 . {s2, s2, s2, s2, s2, s2, s2, s2, s2, s2, er}, // s1 {s2, s2, s2, s2, s2, s2, s2, s2, s2, s2, s3}, // s2 {s3, s3, s3, s3, s3, s3, s3, s3, s3, s3, er}, // s3 {er, er, er, er, er, er, er, er, er, er, er}, // er }; int scan_real_number(void) { char c; while (1) { c = getchar(); // get next char if (c==EOF) break; // end? cur = delta[cur].next[lookup(c)]; } // while // check for accepting state

if (cur!=s2 && cur!=s3)
 return error;

else return success; } δ 1 2 3 4 5 6 7 8 9 . s1 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 er s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s2 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 s3 er

What is the task of the function call lookup(c) here and how would you implement it?

Beware: there's a subtle but
 potentially dangerous bug
 in the code! Can you find it?

Compiler Construction 02: Compiler Structure, Scanning

30

Scanner generators

• Programming a word-class recognizer (lexical analyzer, or

scanner) with ad-hoc logic is complicated and error-prone

• Writing one using tables is a bit easier, but it requires

punching in a bunch of boring table entries to represent specific DFAs

• Can we generate code for a scanner automatically from a

simple description?

• Specify word classes as regular expressions
• Let a program write a large table of states that includes all
• f the expressions
• More on this next week!
