Cloud Analytics Data Warehousing

Marco Serafini

COMPSCI 532 Lecture 18

22

Trivia

• How does Amazon make money?
• Selling books?
• Entertainment?

33

Migrating to the Cloud

• ELASTICITY
• Pay-as-you-go
• Unlimited scale
• COST
• HW procurement at scale
• Cluster management at scale

44

Cloud Computing

• Shared resources
• Multiple tenants sharing resources (with isolation)
• Economy of scale
• Elastic provisioning
• Can easily add and remove resources on the fly
• Pay as you go only when used
• Different flavors
• IaaS, PaaS, SaaS
• Public, private cloud

55

Cloud Offerings

• Computing nodes
• Example: AWS EC2
• Full nodes with local storage and pre-installed OS
• Very large number of instance types: compute optimized,

memory optimized, storage optimized, with GPUs, burstable…

• Storage services
• Example: AWS S3
• Key-value stores (put/get), file systems
• Higher-level services
• Example: DBMS

66

Storage Disaggregation

• Computing nodes (e.g. EC2)
• Feature-rich machines
• Storage services (e.g. S3)
• On cheaper, storage-heavy machines
• Limited read/write interface
• Advantages for cloud provider
• Provision storage and computation independently
• Advantages for users
• Storage services cheaper
• Network bandwidth ~ I/O bandwidth

7

7

Cloud Storage Types

STORAGE PERFORMANC E ACCESS APPENDS AVAILABILITY PRICE OBJECT (S3)

• Shared

X ✓ Low FILE SYSTEM (EFS)

• Shared

✓ ✓ High BLOCK (EBS) + Instance (*) ✓ X Mid INSTANCE-LOCAL ++ Instance ✓ X High (**) (*) Can be detached from an instance and reattached to another (**) Storage-heavy instances are expensive

88

From Shared-Nothing Architecture…

COMPUTE COMPUTE COMPUTE COMPUTE LS LS LS LS

Principle: move computation to data

99

…To Hybrid Architectures

COMPUTE COMPUTE COMPUTE COMPUTE LS LS LS LS STORAGE SERVICE

Arbitrary computation Read/Write only Cannot move computation to data!

10

10

Scheduling Low-Priority Tasks

• Helps increase hardware utilization
• Spot instances
• Allocated in real-time based on live bidding
• Can be revoked any time (with notice)
• Serverless computing
• Example: AWS Lambda
• Each of these services comes with own pricing

12 12

Goals: Push-Button Analytics

• Easily parallelize single-threaded code
• Eliminate cluster management overhead
• Deployment of nodes
• Installation
• Configuration
• Even cloud offerings have their complexities
• Many instance types
• Many services
• Solution: Serverless functions

13

13

Goal: Push-Button Analytics

• Use ”serverless” components
• No need to select a specific cluster size
• System auto-scales up and down on demand
• Building blocks
• Serverless functions (AWS Lambdas)
• Cloud storage services (AWS S3)
• This paper implements MapReduce in this setting

14

14

Serverless Functions

• Single threaded code
• Invoked through HTTP requests
• Cloud platform takes care of
• Deployment
• Load balancing
• Performance isolation
• No need to
• Deploy servers
• Configure clusters

15

15

Challenges with Lambdas

• No local storage, need to use remote cloud storage
• For example S3
• No function-to-function communication
• Again need remote storage to share remote memory
• Short maximum running time

16

16

Remote vs. Local Storage

17

17

State and Fault Tolerance

• State is lost after execution
• Inputs and outputs need to be persisted
• Fault tolerance
• Re-execute function
• Require atomic writes to check what has succeeded

18

18

Registering Functions

• Registering a new Lambda function is slow
• Solution
• Register a single generic Lambda function
• Serialize the code that needs the be executed
• Store the code (and the input data) on S3
• Generic Lambda function loads code and executes it

19

19

Remote Storage Scalability

20

20

Semantics

• Map is easy
• Execute one function per element of the list
• Map + single Reducer
• E.g. parallel featurization + single-server ML
• MapReduce
• Many Lambdas needed, many small intermediate files
• Use Redis, an in-memory key-value store
• Parameter server
• Use Redis

21

21

The Cost of Scaling Up

• Using more nodes does not always imply higher cost
• Lower latency à lower cost per node

22

Data Warehousing Architectures

23 23

Data Warehousing

• Analytical (OLAP) relational queries
• Different architectures
• Snowflake: shared-disk + caching at compute nodes
• Redshift: shared-nothing, store all data at compute nodes
• Redshift Spectrum: serverless workers executing on-demand

and reading from S3

• Let’s discuss these architectures and compare them

24 24

Snowflake

• Shared-disk architecture
• Data is stored on S3, all nodes can access it
• But nodes keep a distributed cache
• Challenges
• Heterogeneous workloads
• No one-size-fits-all hardware configuration
• Membership changes
• Large data shuffles when a node fails/is removed
• Online upgrade
• It is similar to changing all the nodes in the system

25

25

Snowflake Architecture

• Data Storage
• Based on S3: high throughput, high

latency

• Used also for intermediate data
• Virtual Warehouses
• Responsible for query execution
• Stateless (restarted in their entirety)
• Shared cache (low latency on hot

data, most data cold)

• Cloud Services
• Query parsing, access control,
• ptimization
• Snapshot isolation with multi-

versioning

• Metadata on external key-value

store

26

26

Snowflake Advantages

• Storage on S3 is cheaper
• Use expensive local disk only for hot data
• All services (except storage) are stateless
• Simpler fault tolerance and membership change

27 27

Redshift

• Classical shared-nothing architecture
• Initially based on PostgreSQL but heavily re-optimized for

OLAP

• Runs on EC2, explicit provisioning
• All data pre-loaded on instance storage
• Query compilation
• S3 for backup only

28

28

Redshift Spectrum

• Serverless query executor
• Number of workers dynamically assigned
• Stateless
• Reads data directly from S3
• Scale out to leverage storage and computation

bandwidth

30 30

Comparison Setup

• Benchmark: TPC-H
• 1 TB uncompressed data
• 1 execution of the query suite
• Configuration
• Default: 4 nodes, memory
• ptimized (r4 8xlarge)
• Redshift: analogous node that
• ffers SSD storage (dc2)
• Athena: opaque

31

31

Comparison: Initialization Time

• Paid every time we shut

down and restart the system

• Load metadata and

(optionally) data

32

32

Comparison: Runtime

• Pre-loading pays off
• Initialization delay is easily

amortized

• Caching less helpful
• Cost
• Athena: pay data scan only
• Other systems: mainly running

time

• Spectrum: scan + running time

33

33

Comparison: Execution Cost

• RS can amortize

loading costs

• Athena
• Servlerless
• Pay per amount of

data scanned

• RS Spectrum
• Similar scheme as

Athena

• But must add RS

cluster cost

34

34

Storage Cost Per Day

EBS very expensive Instance storage + S3 backup cheaper

35

35

Pushing Down Computation?

• One should always move computation to data
• But disaggregated storage cannot compute!

COMPUTE COMPUTE COMPUTE COMPUTE LS LS LS LS STORAGE SERVICE

Arbitrary computation Read/Write only

36 36

S3 Select

• Computation on the storage layer
• Simple selection and projection queries on structured data

(e.g. CSV or Parquet)

• Simple aggregations (e.g. sum)

37

PusdownDB

• Stateless query execution

with S3 select

• Example: Bloom join
• Standard hash join but push

down Bloom filter to filter results that will not join

38

38

TPC-H Results

• Great speedups with S3 select
