Chw00t: How to break out from various chroot solutions Balzs Bucsay OSCE, OSCP , GIAC GPEN, OSWP http://rycon.hu/ - https://www.mrg-effitas.com/ @xoreipeip Bio / Balazs Bucsay Hungarian Hacker Strictly technical certificates: OSCE,

slide-1
SLIDE 1

Chw00t: How to break out from various chroot solutions

Balázs Bucsay

OSCE, OSCP , GIAC GPEN, OSWP http://rycon.hu/ - https://www.mrg-effitas.com/ @xoreipeip

slide-2
SLIDE 2

Bio / Balazs Bucsay

  • Hungarian Hacker
  • Strictly technical certificates: OSCE, OSCP

, OSWP and GIAC GPEN

  • Works for MRG Effitas - research, AV/endpoint security product tests
  • Started with ring0 debuggers and disassemblers in 2000 (13 years
  • ld)
  • Major project in 2009: GI John a distributed password cracker
  • Presentations around the world (Atlanta, Moscow, London, Oslo)
  • Webpage: http://rycon.hu
  • Twitter: @xoreipeip
  • Linkedin: http://www.linkedin.com/in/bucsayb
slide-3
SLIDE 3

Chroot’s brief history

  • Introduced in Version 7 Unix - 1979
  • Inherited from V7 UNIX to BSD - 1982
  • Hardened version was implemented in FreeBSD - 2000
  • Virtuozzo (OpenVZ) containers - 2000
  • Chroot on Steroids: Solaris container - 2005
  • LXC: Linux Containers - 2008
slide-4
SLIDE 4

What is Chroot?

  • A privileged system call on Unix systems
  • Changes the dedicated root vnode of a process (all

children inherit this)

  • Some OS stores chroots in linked lists
  • Prevents access to outside of the new root
  • Requires root: prevents crafted chroots for privilege

escalation

slide-5
SLIDE 5

What’s this used for?

  • Testing environments
  • Dependency control
  • Compatibility
  • Recovery
  • Privilege separation??
slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8

Requirements for reasonable chroot

  • All directories must be root:root owned
  • Superuser process cannot be run in chroot
  • Distinct and unique user (uid, gid) has to be used
  • No sensitive files (or files at all) can be modified or

created

slide-9
SLIDE 9

Requirements for reasonable chroot

  • Close all file descriptors before chrooting
  • chdir before chroot
  • /proc should not be mounted
  • + Use /var/empty for empty environment
slide-10
SLIDE 10

Chroot scenarios

Shell access:

  • SSH access to a chrooted environment
  • Chrooted Apache running with mod_cgi/mod_php/…
  • Exploiting a vulnerable chrooted app

Only filesystem access:

  • Chrooted SCP/FTP access
slide-11
SLIDE 11

Breakage techniques

mostly summarised

  • Get root (not all techniques need it)
  • Get access to a directory’s file descriptor outside of the

chroot

  • Find original root
  • Chroot into that
  • Escaped
  • Only a few OS stores chroots in linked lists, if you can break
  • ut of one, you broke out all of them
slide-12
SLIDE 12

Example structure
 Original root

/ bin etc home usr chroot user1 user2 bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-13
SLIDE 13

Example structure
 New root (chrooted once)

/chroot bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-14
SLIDE 14

Example structure
 New root (chrooted twice)

/chroot2 etc home usr user7 bin user6

slide-15
SLIDE 15

Breakage techniques: kernel exploit/module


 Not going to talk about this

#root: MIGHT needed

slide-16
SLIDE 16

Breakage techniques: misconfigurations

  • Hard to recognise and exploit
  • Wrong permissions on files or directories
  • Dynamic loading of shared libraries
  • Hardlinked suid/sgid binaries using chrooted shared libraries
  • For example:
  • /etc/passwd ; /etc/shadow
  • /lib/libpam.so.0 - used by /bin/su
  • These can be used to run code as root

#root: NOT needed

slide-17
SLIDE 17

Breakage techniques: classic

  • Oldest and most trivial
  • mkdir(d); chroot(d); cd ../../../; chroot(.)
  • chroot syscall does not chdir into the directory, stays
  • utside

#root: needed

slide-18
SLIDE 18

Root and CWD

/ bin etc home usr / user1 user2 bin etc home usr user4 user3 user5

slide-19
SLIDE 19

Root barrier and CWD

/ bin etc home usr / user1 user2 bin etc home usr user4 / user5

slide-20
SLIDE 20

Root barrier and CWD

/ bin etc home usr / user1 user2 bin etc home usr user4 / user5

slide-21
SLIDE 21

Breakage techniques: classic+fd saving

  • Based on the classic
  • Saving the file descriptor of CWD before chroot
  • mkdir(d); n=open(.); chroot(d); fchdir(n); cd ../../../../;

chroot(.)

  • Some OS might change the CWD to the chrooted one

#root: needed

slide-22
SLIDE 22

Root, CWD and saved fd

/ bin etc home usr / user1 user2 bin etc home usr user4 user3 user5

slide-23
SLIDE 23

Root barrier and saved fd

/ bin etc home usr / user1 user2 bin etc home usr user4 / user5

slide-24
SLIDE 24

Root barrier and saved fd

/ bin etc home usr / user1 user2 bin etc home usr user4 / user5

slide-25
SLIDE 25

Breakage techniques: Unix Domain Sockets

  • UDS are similar to Internet sockets
  • File descriptors can be passed thru
  • Creating secondary chroot and passing outside fd thru
  • Or using outside help (not really realistic)
  • Abstract UDS does not require filesystem access

#root: needed

slide-26
SLIDE 26

Root(0) and CWD

/ bin etc home usr chroot user1 user2 bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-27
SLIDE 27

Root barrier(1) parent forks

/ bin etc home usr / user1 user2 bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-28
SLIDE 28

Root barrier(2) forked child

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-29
SLIDE 29

Root barrier(1) and FD (UDS)

/ bin etc home usr / user1 user2 bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-30
SLIDE 30

Child Root barrier(2) and FD (UDS)

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-31
SLIDE 31

Child Root barrier(2) and FD (UDS)

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-32
SLIDE 32

Breakage techniques: mount()

  • Mounting root device into a directory
  • Chrooting into that directory
  • Linux is not restrictive on mounting

#root: needed

slide-33
SLIDE 33

Breakage techniques: /proc

  • Mounting procfs into a directory
  • Looking for a pid that has a different root/cwd entry
  • for example: /proc/1/root
  • chroot into that entry

#root: needed

slide-34
SLIDE 34

Breakage techniques: move-out-of-chroot

  • The reason why I started to work on this
  • Creating chroot and a directory in it
  • Use the directory for CWD
  • Move the directory out of the chroot

#root: MIGHT needed

slide-35
SLIDE 35

Root(0) and CWD

/ bin etc home usr chroot user1 user2 bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-36
SLIDE 36

Root barrier(1) parent forks

/ bin etc home usr / user1 user2 bin etc home usr user3 chroot2 user4 user5 etc home usr user7 bin user6

slide-37
SLIDE 37

Root barrier(2) forked child

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-38
SLIDE 38

Root barrier(2) and CWD

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-39
SLIDE 39

Root barrier(2) and user7 moved out

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-40
SLIDE 40

Root barrier(2) and user7 moved out

/ bin etc home usr chroot user1 user2 bin etc home usr user3 / user4 user5 etc home usr user7 bin user6

slide-41
SLIDE 41

Breakage techniques: ptrace()

  • System call to observe other processes
  • Root can attach to any processes
  • User can attach to same uid processes (when

euid=uid)

  • Change original code and run shellcode

#root: NOT needed

slide-42
SLIDE 42

Question

Tell me a service that is usually chrooted

slide-43
SLIDE 43

DEMO

slide-44
SLIDE 44

Results

Debian 7.8;2.6.32/Kali 3.12 Ubuntu 14.04.1;3.13.0-32- generic DragonFlyBSD 4.0.5 x86_64 FreeBSD 10.- RELEASE amd64 NetBSD 6.1.4 amd64 OpenBSD 5.5 amd64 Solaris 5.11 11.1 i386 Mac OS X Classic YES YES DoS NO NO NO YES YES Classic FD YES YES NO NO NO NO YES YES Unix Domain Sockets YES YES DoS PARTIALLY NO PARTIALLY? YES YES /proc YES YES NO NO NO NO YES NO Mount YES YES NO NO NO NO NO NO move out of chroot YES YES DoS PARTIALLY NO YES YES YES Ptrace YES PARTIALLY NO? YES NO YES N/A N/A

slide-45
SLIDE 45

Results (FreeBSD jail)

FreeBSD 10. - RELEASE amd64 FreeBSD 10. Jail - RELEASE amd64 Classic NO NO Classic FD NO NO Unix Domain Sockets PARTIALLY PARTIALLY Mount NO NO /proc NO NO move-out-of-chroot PARTIALLY PARTIALLY Ptrace YES NO

slide-46
SLIDE 46

Filesystem access only

  • Move-out-of-chroot still works on FTP/SCP
  • Privilege escalation is possible on misconfigured

environment

  • Shell can be popped by replacing or placing shared

libraries/malicious files in chroot

slide-47
SLIDE 47

Linux Containers

  • Privileged container (no user namespaces) can create

nested containers

  • Host container has access to guest container’s

filesystem

  • Based on the move-out-of-chroot technique, real

host’s file system is accessible

slide-48
SLIDE 48

DEMO 2

slide-49
SLIDE 49

Tool

https://www.github.com/earthquake/chw00t/

slide-50
SLIDE 50

Future work

  • Testing new UNIX operating systems (eg. AIX, HP-UX)
  • Looking for other techniques
slide-51
SLIDE 51

Future work

slide-52
SLIDE 52

Greetz to:

  • My girlfriend and family
  • Wolphie and Solar Designer for mentoring
  • Spender and Kristof Feiszt for reviewing
slide-53
SLIDE 53

References

  • http://www.bpfh.net/simes/computing/chroot-break.html
  • http://www.unixwiz.net/techtips/chroot-practices.html
  • http://linux-vserver.org/Secure_chroot_Barrier
  • http://phrack.org/issues/59/12.html
  • http://lwn.net/Articles/421933/
  • https://securityblog.redhat.com/2013/03/27/is-chroot-a-

security-feature/

slide-54
SLIDE 54

http://rycon.hu - https://www.mrg-effitas.com/ https://github.com/earthquake

@xoreipeip

Thank you

  • Q&A
