CS 2412 Data Structures Chapter 9 Graphs Some concepts A graph consists of a set of vertices and a set of lines (edges, arcs). A directed graph, or digraph, is a graph in which each line has a direction. Usually, the lines are called

slide-1
SLIDE 1

CS 2412 Data Structures

Chapter 9 Graphs

slide-2
SLIDE 2

Some concepts

  • A graph consists of a set of vertices and a set of lines (edges,

arcs).

  • A directed graph, or digraph, is a graph in which each line has

a direction. Usually, the lines are called arcs.

  • A path is a sequence of vertices in which each vertex is

adjacent to the next one, where adjacent means that there is an line from one to the next one.

  • A cycle is a path consisting of at least three vertices that starts

and ends with the same vertex.

  • A loop is a single arc from a vertex to itself.
  • A connected graph is a graph in which any pair of vertices has

a path between them.

Data Structure 2016

  • R. Wei

2

slide-3
SLIDE 3

For a directed graph:

  • Strong connected if there is a path from each vertex to every
  • ther vertex.
  • Weakly connected if there is a path from each vertex to every
  • ther vertex when the direction of the arc is ignored, but at

least two vertices are not connected when we consider the direction of the path.

  • The outdegree of a vertex is the number of arcs leaving the

vertex.

  • The indegree is the number of arcs entering the vertex.

Data Structure 2016

  • R. Wei

3

slide-4
SLIDE 4

Data Structure 2016

  • R. Wei

4

slide-5
SLIDE 5

Data Structure 2016

  • R. Wei

5

slide-6
SLIDE 6

Data Structure 2016

  • R. Wei

6

slide-7
SLIDE 7

Operations

  • Inset a vertex: add a new vertex to the graph.
  • Delete a vertex: removed a vertex from the graph and all edges

connected to that vertex are also removed.

  • Add an edge: two vertices must be specified to add an edge.

For a digraph, one vertex must be specified as the source and

  • ther one as the destination.
  • Delete an edge: remove an edge from the graph.

Data Structure 2016

  • R. Wei

7

slide-8
SLIDE 8

Traverse graph:

  • Depth-first traversal: Suppose the traversal has just visited a

vertex v which is adjacent to vertices w1, w2, · · · , wk. Then the traversal visit w1 and traverse all the vertices to which it is adjacent before returning to traverse w2, · · · , wk.

  • Breadth-first traversal: Suppose the traversal has just visited a

vertex v. Then it next visits all the vertices adjacent to v.

Data Structure 2016

  • R. Wei

8

slide-9
SLIDE 9

We can use a recursive method to implement graph traverse. But we also can use a stack to implement. Depth-first traversal:

  • 1. Push the first vertex into the stack.
  • 2. Loop:

pop a vertex from the stack process the vertex push all of the adjacent vertices into the stack.

  • 3. When the stack is empty, the traversal is complete.

Data Structure 2016

  • R. Wei

9

slide-10
SLIDE 10

Data Structure 2016

  • R. Wei

10

slide-11
SLIDE 11

Use a queue to implement the breadth-first traversal:

  • 1. Enqueue the first vertex into the queue.
  • 2. Loop:

dequeue a vertex from the Process the vertex. place all of its adjacent vertices into the queue.

  • 3. When the queue is empty, the traversal is complete.

Data Structure 2016

  • R. Wei

11

slide-12
SLIDE 12

Data Structure 2016

  • R. Wei

12

slide-13
SLIDE 13

Graph representation

  • Adjacency matrix: a 0-1 matrix its rows and columns are

indexed by vertices. The cell i, j is 1 if and only if the ith vertex and the jth vertex is adjacent. The matrix of a non-directed graph must be symmetric to its main diagonal.

  • Adjacency list: a list of vertices that are adjacent to the vertex.

Each vertex has a adjacent list (unless it is isolated).

Data Structure 2016

  • R. Wei

13

slide-14
SLIDE 14

Data Structure 2016

  • R. Wei

14

slide-15
SLIDE 15

There are different methods to implement graphs. The following implementation are based on the adjacent list.

Data Structure 2016

  • R. Wei

15

slide-16
SLIDE 16

Data Structure 2016

  • R. Wei

16

slide-17
SLIDE 17

typedef struct { int count; struct vertex* first; int (*compare) (void* argu1, void* argu2); } GRAPH; typedef struct vertex { struct vertex* pNextVertex; void* dataPtr; int inDegree; int

  • utDegree;

short processed; struct arc* pArc; } VERTEX; typedef struct arc { struct vertex* destination; struct arc* pNextArc; } ARC;

Data Structure 2016

  • R. Wei

17

slide-18
SLIDE 18

To create a graph is simple.

Data Structure 2016

  • R. Wei

18

slide-19
SLIDE 19

GRAPH* graphCreate (int (*compare) (void* argu1, void* argu2)) { GRAPH* graph; graph = (GRAPH*) malloc (sizeof (GRAPH)); if (graph) { graph->first = NULL; graph->count = 0; graph->compare = compare; } // if return graph; } // graphCreate

Data Structure 2016

  • R. Wei

19

slide-20
SLIDE 20

For the insertion and deletion of vertex in a graph with adjacency list implementation:

  • The vertex list is arranged in order (usually in the increasing
  • rder corresponding to the keys).
  • For insertion, first insert the vertex to the vertex list according

to the order of key. Then insert the related edges.

  • For deletion, first delete the edges connected to the vertex that

will be deleted. Then delete the vertex.

  • We only consider the graph here. But the implementation of

digraph is similar.

Data Structure 2016

  • R. Wei

20

slide-21
SLIDE 21

Data Structure 2016

  • R. Wei

21

slide-22
SLIDE 22

void graphInsVrtx (GRAPH* graph, void* dataInPtr) { VERTEX* newPtr; VERTEX* locPtr; VERTEX* predPtr; newPtr = (VERTEX*)malloc(sizeof (VERTEX)); if (newPtr) { newPtr->pNextVertex = NULL; newPtr->dataPtr = dataInPtr; newPtr->inDegree = 0; newPtr->outDegree = 0; newPtr->processed = 0; newPtr->pArc = NULL; (graph->count)++; } // if malloc else printf("Overflow error 100\a\n"), exit (100); locPtr = graph->first;// Now find insertion point if (!locPtr)

Data Structure 2016

  • R. Wei

22

slide-23
SLIDE 23

graph->first = newPtr; else { predPtr = NULL; while (locPtr && (graph->compare (dataInPtr, locPtr->dataPtr) > 0)) { predPtr = locPtr; locPtr = locPtr->pNextVertex; } // while if (!predPtr) graph->first = newPtr; else predPtr->pNextVertex = newPtr; newPtr->pNextVertex = locPtr; } // else return; } // graphInsVrtx

Data Structure 2016

  • R. Wei

23

slide-24
SLIDE 24

Data Structure 2016

  • R. Wei

24

slide-25
SLIDE 25

int graphDltVrtx (GRAPH* graph, void* dltKey) { VERTEX* predPtr; VERTEX* walkPtr; if (!graph->first) return -2; predPtr = NULL; walkPtr = graph->first; while (walkPtr && (graph->compare(dltKey, walkPtr->dataPtr) > 0)) { predPtr = walkPtr; walkPtr = walkPtr->pNextVertex; } // walkPtr && if (!walkPtr || graph->compare(dltKey, walkPtr->dataPtr) != 0)

Data Structure 2016

  • R. Wei

25

slide-26
SLIDE 26

return -2; // then found vertex. Test degree if ((walkPtr->inDegree > 0) || (walkPtr->outDegree > 0)) return -1; if (!predPtr) //delete graph->first = walkPtr->pNextVertex; else predPtr->pNextVertex = walkPtr->pNextVertex;

  • -graph->count;

free(walkPtr); return 1; } // graphDltVrtx

Data Structure 2016

  • R. Wei

26

slide-27
SLIDE 27

Data Structure 2016

  • R. Wei

27

slide-28
SLIDE 28

Data Structure 2016

  • R. Wei

28

slide-29
SLIDE 29

int graphInsArc (GRAPH* graph, void* pFromKey, void* pToKey) { ARC* newPtr; ARC* arcPredPtr; ARC* arcWalkPtr; VERTEX* vertFromPtr; VERTEX* vertToPtr; newPtr = (ARC*)malloc(sizeof(ARC)); if (!newPtr) return (-1); //locate source vertex vertFromPtr = graph->first; while (vertFromPtr && (graph->compare(pFromKey, vertFromPtr->dataPtr) > 0)) { vertFromPtr = vertFromPtr->pNextVertex; } if (!vertFromPtr || (graph->compare(pFromKey, vertFromPtr->dataPtr) != 0))

Data Structure 2016

  • R. Wei

29

slide-30
SLIDE 30

return (-2); vertToPtr = graph->first; while (vertToPtr && graph->compare(pToKey, vertToPtr->dataPtr) > 0) { vertToPtr = vertToPtr->pNextVertex; } if (!vertToPtr || (graph->compare(pToKey, vertToPtr->dataPtr) != 0)) return (-3); // From and to vertices located. Insert new arc ++vertFromPtr->outDegree; ++vertToPtr

  • >inDegree;

newPtr->destination = vertToPtr; if (!vertFromPtr->pArc) { // Inserting first arc for this vertex vertFromPtr->pArc = newPtr; newPtr-> pNextArc = NULL; return 1;

Data Structure 2016

  • R. Wei

30

slide-31
SLIDE 31

} // Find insertion point in adjacency (arc) list arcPredPtr = NULL; arcWalkPtr = vertFromPtr->pArc; while (arcWalkPtr && graph->compare(pToKey, arcWalkPtr->destination->dataPtr) >= 0) { arcPredPtr = arcWalkPtr; arcWalkPtr = arcWalkPtr->pNextArc; } // arcWalkPtr && if (!arcPredPtr) // Insertion before first arc vertFromPtr->pArc = newPtr; else arcPredPtr->pNextArc = newPtr; newPtr->pNextArc = arcWalkPtr; return 1; } // graphInsArc

Data Structure 2016

  • R. Wei

31

slide-32
SLIDE 32

Data Structure 2016

  • R. Wei

32

slide-33
SLIDE 33

Data Structure 2016

  • R. Wei

33

slide-34
SLIDE 34

int graphDltArc (GRAPH* graph, void* fromKey, void* toKey) { VERTEX* fromVertexPtr; VERTEX* toVertexPtr; ARC* preArcPtr; ARC* arcWalkPtr; if (!graph->first) return -2; // Locate source vertex fromVertexPtr = graph->first; while (fromVertexPtr && (graph->compare(fromKey, fromVertexPtr->dataPtr) > 0)) fromVertexPtr = fromVertexPtr->pNextVertex; if (!fromVertexPtr || graph->compare(fromKey, fromVertexPtr->dataPtr) != 0) return -2; // Locate destination vertex in adjacency list if (!fromVertexPtr->pArc) return -3; preArcPtr = NULL; arcWalkPtr = fromVertexPtr->pArc; while (arcWalkPtr && (graph->compare(toKey,

Data Structure 2016

  • R. Wei

34

slide-35
SLIDE 35

arcWalkPtr->destination->dataPtr) > 0)) { preArcPtr = arcWalkPtr; arcWalkPtr = arcWalkPtr->pNextArc; } // while arcWalkPtr && if (!arcWalkPtr || (graph->compare(toKey, arcWalkPtr->destination->dataPtr) != 0)) return -3; toVertexPtr = arcWalkPtr->destination; // from, toVertex & arcPtr located. Delete arc

  • -fromVertexPtr->outDegree;
  • -toVertexPtr -> inDegree;

if (!preArcPtr) // Deleting first arc fromVertexPtr->pArc = arcWalkPtr->pNextArc; else preArcPtr->pNextArc = arcWalkPtr->pNextArc; free (arcWalkPtr); return 1; } // graphDltArc

Data Structure 2016

  • R. Wei

35

slide-36
SLIDE 36

Data Structure 2016

  • R. Wei

36

slide-37
SLIDE 37

int graphRetrVrtx (GRAPH* graph, void* keyPtr, void** pDataOut) { VERTEX* walkPtr; if (!graph->first) return -2; walkPtr = graph->first; while (walkPtr && (graph->compare (keyPtr, walkPtr->dataPtr) > 0)) walkPtr = walkPtr->pNextVertex; if (graph->compare(keyPtr, walkPtr->dataPtr) == 0) { *pDataOut = walkPtr->dataPtr; return 1; } // if else return -2; } // graphRetrVrtx

Data Structure 2016

  • R. Wei

37

slide-38
SLIDE 38

Data Structure 2016

  • R. Wei

38

slide-39
SLIDE 39

Data Structure 2016

  • R. Wei

39

slide-40
SLIDE 40

void graphDpthFrst (GRAPH* graph, void (*process) (void* dataPtr)) { bool success; VERTEX* walkPtr; VERTEX* vertexPtr; VERTEX* vertToPtr; STACK * stack; ARC* arcWalkPtr; if (!graph->first) return; // Set processed flags to not processed walkPtr = graph->first; while (walkPtr) { walkPtr->processed = 0; walkPtr = walkPtr->pNextVertex; } // while // Process each vertex in list stack = createStack (); walkPtr = graph->first;

Data Structure 2016

  • R. Wei

40

slide-41
SLIDE 41

while (walkPtr) { if (walkPtr->processed < 2) { if (walkPtr->processed < 1) { // Push & set flag to pushed success = pushStack (stack, walkPtr); if (!success) printf("\aStack overflow 100\a\n"), exit (100); walkPtr->processed = 1; } // if processed < 1 } // if processed < 2 // Process descendents of vertex at stack top while (!emptyStack (stack)) { vertexPtr = popStack(stack); process (vertexPtr->dataPtr); vertexPtr->processed = 2; // Push all vertices from adjacency list

Data Structure 2016

  • R. Wei

41

slide-42
SLIDE 42

arcWalkPtr = vertexPtr->pArc; while (arcWalkPtr) { vertToPtr = arcWalkPtr->destination; if (vertToPtr->processed == 0) { success = pushStack(stack, vertToPtr); if (!success) printf("\aStack overflow 101\a\n"), exit (101); vertToPtr->processed = 1; } // if vertToPtr arcWalkPtr = arcWalkPtr->pNextArc; } // while pWalkArc } // while !emptyStack walkPtr = walkPtr->pNextVertex; } // while walkPtr destroyStack(stack); return; } // graphDpthFrst

Data Structure 2016

  • R. Wei

42

slide-43
SLIDE 43

void graphBrdthFrst (GRAPH* graph, void (*process) (void* dataPtr)) { bool success; VERTEX* walkPtr; VERTEX* vertexPtr; VERTEX* vertToPtr; QUEUE* queue; ARC* arcWalkPtr; if (!graph->first) return; // Set processed flags to not processed walkPtr = graph->first; while (walkPtr) { walkPtr->processed = 0; walkPtr = walkPtr->pNextVertex; } // while // Process each vertex in list queue = createQueue (); walkPtr = graph->first;

Data Structure 2016

  • R. Wei

43

slide-44
SLIDE 44

while (walkPtr) { if (walkPtr->processed < 2) { if (walkPtr->processed < 1) { // Enqueue & set flag to queue success = enqueue(queue, walkPtr); if (!success) printf("\aQueue overflow 100\a\n"), exit (100); walkPtr->processed = 1; } // if processed < 1 } // if processed < 2 // Process descendents of vertex at que frnt while (!emptyQueue (queue)) { dequeue(queue, (void**)&vertexPtr); process (vertexPtr->dataPtr); vertexPtr->processed = 2; // Enqueue vertices from adjacency list

Data Structure 2016

  • R. Wei

44

slide-45
SLIDE 45

arcWalkPtr = vertexPtr->pArc; while (arcWalkPtr) { vertToPtr = arcWalkPtr->destination; if (vertToPtr->processed == 0) { success = enqueue(queue, vertToPtr); if (!success) printf("\aQueue overflow 101\a\n"), exit (101); vertToPtr->processed = 1; } // if vertToPtr arcWalkPtr = arcWalkPtr->pNextArc; } // while pWalkArc } // while !emptyQueue walkPtr = walkPtr->pNextVertex; } // while walkPtr destroyQueue(queue); return; } // graphBrdthFrst

Data Structure 2016

  • R. Wei

45

slide-46
SLIDE 46

Data Structure 2016

  • R. Wei

46

slide-47
SLIDE 47

Weighted graph Weighted graph is a graph whose edges are weighted. The meaning

  • f the weights depends on the applications.

Sometimes, a weighted graph is also called a network. Example:

Data Structure 2016

  • R. Wei

47

slide-48
SLIDE 48

Two methods can be used to store a weighted graph:

Data Structure 2016

  • R. Wei

48

slide-49
SLIDE 49

Minimum spanning tree A spanning tree contains all of the vertices in a connected graph. A minimum spanning tree is a spanning tree in which the total weight

  • f the edges is the minimum of all possible spanning trees in the

graph. Example: Find a minimum spanning tree for the network:

Data Structure 2016

  • R. Wei

49

slide-50
SLIDE 50

The main idea: Start from any vertex, say A. Put A into the set S. Consider all the edges connected to A and find out the minimum weight edge, say the edge connect to C. Put C in S and put edge AC to the tree T. In general, consider all the edges connected to a vertex in S, but the vertex of the other end of the edge is not in S. Select the minimum weight edge which is then put in the tree T. The vertex

  • f the other end of the edge is also put in S.

If S contains all the vertices of the graph, output T.

Data Structure 2016

  • R. Wei

50

slide-51
SLIDE 51

Data Structure 2016

  • R. Wei

51

slide-52
SLIDE 52

Data structure for spanning tree of graph: We use adjacency list implementation which is similar to the previous implementation of graphs. The main differences are:

  • For graph vertex, inTree are used instead of processed.

inTree is a indicator to indicate if the vertex is included in the spanning tree.

  • For graph edge, weight and inTree are added. The weight

is used to record the weight of the edge and inTree is used to indicate if the edge is included in the spanning tree.

Data Structure 2016

  • R. Wei

52

slide-53
SLIDE 53

Data Structure 2016

  • R. Wei

53

slide-54
SLIDE 54

Data Structure 2016

  • R. Wei

54

slide-55
SLIDE 55

Shortest path: Dijkstra algorithm A shortest path between two vertices in a network is a path with minimum weights. Dijkstra algorithm is used to find the shortest path between any two nodes in a graph:

  • Insert the first vertex into the tree.
  • From every vertex already in the tree, check the total path to

all adjacent vertices not in the tree. Select the edge with the minimum total path weight and insert it into the tree.

  • Repeat above step until all vertices are in the tree.

Data Structure 2016

  • R. Wei

55

slide-56
SLIDE 56

Data Structure 2016

  • R. Wei

56

slide-57
SLIDE 57

Data Structure 2016

  • R. Wei

57

slide-58
SLIDE 58

Algorithm shortestPath (graph)

Data Structure 2016

  • R. Wei

58

slide-59
SLIDE 59

Data Structure 2016

  • R. Wei

59

slide-60
SLIDE 60

The above algorithm is based on adjacency list. We also can use the adjacency matrix to find about the shortest path.

Data Structure 2016

  • R. Wei

60
