BOOLEAN MATRIX AND TENSOR DECOMPOSITIONS

Pauli Miettinen TML 2013 27 September 2013

BOOLEAN MATRIX AND TENSOR DECOMPOSITIONS

• Boolean decompositions are like “normal” decompositions,

except that

• Input is a binary matrix or tensor
• Factors are binary
• Arithmetic is Boolean (so reconstructions are binary)
• Error measure is (usually) Hamming distance (L1)

BOOLEAN ARITHMETIC

• Idenpotent, anti-negative semi-ring ({0,1}, ∨, ∧)
• Like normal arithmetic, but addition is defined as 1+1 = 1
• A Boolean matrix is a binary (0/1) matrix endowned with

Boolean arithmetic

• The Boolean matrix product is defined as


(A B)ij =

R

_

r=1

bilclj

WHY BOOLEAN ARITHMETIC?

• Boolean decompositions find different type of structure than

decompositions under normal arithmetic

• Not better, not worse, just different
• Normal decomposition: value is a sum of values from rank-1

components

• Boolean decomposition: value is 1 if there is any rank-1

component with 1 in this location

WHY BOOLEAN CONT’D

1 1 1 1 1 1 1

( )

1 2 3 A B C 1 3 2

A C B Boolean artihmetic can be interpret as set operations

EXAMPLE

1 1 1 1 1 1 1

( )

1 1 1 1

( )

1 1 1 1

( )

= × ○ A B C Real analysis

• Discr. math.

Programming E-mail Internet Contacts

RESULTS ON BOOLEAN MATRIX FACTORIZATION

• Computing the Boolean rank is NP-hard
• As hard to approximate as minimum chromatic number
• Minimum-error decomposition is NP-hard
• And hard to approximate in both additive and multiplicative sense
• Given A and B, finding C such that B￮C is close to A is hard even to

approximate

Alternating updates are hard!

SOME MORE RESULTS

• Boolean rank can be a logarithm of the real rank
• Sparse matrices have sparse (exact) factorizations
• The rank of the decomposition can be defined automatically

using the MDL principle

• Planted rank-1 matrix can be recovered under XOR noise

(under certain assumptions)

SOME ALGORITHMS

• Alternating least-squares
• Proposed in psychometrical litterature

in early 1980’s

• Asso [M. et al. 2006 & 2008]
• Builds candidate factors based on

correlation matrix, and greedily selects them




• Panda [Lucchese et al. 2010]
• Expands monochromatic core

patterns (tiles) based on MDL-esque rule

• Various tiling algorithms
• Do not allow expressing 0 in data as 1

in factorization (false positives)

• Binary factorizations
• Normal algebra but binary factors

SOME APPLICATIONS

• Explorative data analysis
• Psychometrics
• Role mining
• Pattern mining
• Co-clustering-y applications
• Bipartite community

detection

• Binary matrix completion
• But requires {0, 1, ?} data

RANK-1 (BOOLEAN) TENSORS

X a b

=

X = a × b

X a b c

X = a ×1 b ×2 c

=

THE BOOLEAN CP TENSOR DECOMPOSITION

≈ X a1 a2 aR bR b2 b1 c1 c2 cR ∨ ∨ · · · ∨

xijk ≈

R

_

r=1

airbjrckr

THE BOOLEAN CP TENSOR DECOMPOSITION

X A B C ≈

• xijk ≈

R

_

r=1

airbjrckr

FREQUENT TRI-ITEMSET MINING

• Rank-1 N-way binary tensors define an N-way itemset
• Particularly, rank-1 binary matrices define an itemset
• In itemset mining the induced sub-tensor must be full of 1s
• Here, the items can have holes
• Boolean CP decomposition = lossy N-way tiling

BOOLEAN TENSOR RANK

The Boolean rank of a binary tensor is the minimum number of binary rank-1 tensors needed to represent the tensor exactly using Boolean arithmetic.

=

X a1 a2 aR bR b2 b1 c1 c2 cR ∨ ∨ · · · ∨

SOME RESULTS ON RANKS

• Normal tensor rank is NP-

hard to compute

• Normal tensor rank of


n-by-m-by-k tensor can be more than min{n, m, k}

• But no more than


min{nm, nk, mk}

• Boolean tensor rank is

NP-hard to compute

• Boolean tensor rank of


n-by-m-by-k tensor can be more than min{n, m, k}

• But no more than


min{nm, nk, mk}

SPARSITY

• Binary N-way tensor of Boolean tensor rank R has Boolean

rank-R CP-decomposition with factor matrices A1, A2, …, AN such that ∑i |Ai| ≤ N| |

• Binary matrix X of Boolean rank R and |X| 1s has Boolean

rank-R decomposition A o B such that |A| + |B| ≤ 2|X|

• Both results are existential only and extend to approximate

decompositions


X X

SIMPLE ALGORITHM

• We can use typical alternating

algorithm with Boolean algebra

• Finding the optimal projection is

NP-hard even to approximate

• Good initial values are needed due

to multiple local minima

• Obtained using Boolean matrix

factorization to matricizations

X(1) = A (C B)T X(2) = B (C A)T X(3) = C (B A)T

THE BOOLEAN TUCKER TENSOR DECOMPOSITION

X G A B C ≈

xijk ≈

P

_

p=1 Q

_

q=1 R

_

r=1

gpqraipbjqckr

THE SIMPLE ALGORITHM WITH TUCKER

• The core tensor has global effects
• Updates are hard
• Factors are not orthogonal
• Assume core tensor is small
• We can afford more time per

element

• In Boolean case many changes

make no difference

X

G

A

B C ≈

xijk ≈

P

_

p=1 Q

_

q=1 R

_

r=1

gpqraipbjqckr

WALK’N’MERGE: MORE SCALABLE ALGORITHM

• Idea: For exact decomposition, we could find all N-way tiles
• Then we “only” need to find the ones we need among them
• Problem: For approximate decompositions, there might not

be any big tiles

• We need to find tiles with holes, i.e. dense rank-1

subtensors

TENSORS AS GRAPHS

• Create a graph from the tensor
• Each 1 in the tensor: one vertex in the graph
• Edge between two vertices if they differ in at most one

coordinate

• Idea: If two vertices are in the same all-1s rank-1 N-way subtensor,

they are at most N steps from each other

• Small-diameter subgraphs ⇔ dense rank-1 subtensors

EXAMPLE

  1 1 1 1 1 1     1 1 1 1 1 1 1  

1,1,1 1,1,2 1,2,1 1,2,2 2,1,1 2,1,2 2,2,1 2,2,2 2,3,2 1,4,1 1,4,2 3,1,2 3,3,1

RANDOM WALKS

• We can identify the small-diameter subgraphs by random

walks

• If many (short) random walks re-visit the same nodes often,

they’re on a small-diameter subgraph

• Problem: The random walks might return many overlapping

dense areas and miss the smallest rank-1 decompositions

MERGE

• We can exhaustively look for all small (e.g. 2-by-2-by-2) all-1s

sub-tensors outside the already-found dense subtensors

• We can now merge all partially overlapping rank-1 subtensors

if the resulting subtensor is dense enough

• Result: A Boolean CP-decomposition of some rank
• False positive rate controlled by the density, false negative by

the exhaustive search

MDL STRIKES AGAIN

• We have a decomposition with some rank, but what would be

a good rank?

• Normally: pre-defined by the user (but how does she know)
• MDL principle: The best model to describe your data is the
• ne that does it with the least number of bits
• We can use MDL to choose the rank

HOW YOU COUNT THE BITS?

• MDL asks for an exact representation of the data
• In case of Boolean CP

, we represent the tensor with

• Factor matrices
• Error tensor
• The bit-strings representing these are encoded to compute

the description length X E

WHY MDL AND TUCKER DECOMPOSITION

• Balance between accuracy and complexity
• High rank: more bits in factor matrices, less in error tensor
• Small rank: less bits in factor matrices, more in error tensor
• If one mode uses the same factor multiple times, CP contains it

multiple times

• The Tucker decomposition needs to have that factor only once

FROM CP TO TUCKER WITH MDL

• CP is Tucker with hyper-diagonal core tensor
• If we can remove a repeated column from a factor matrix and

adjust the core accordingly, our encoding is more efficient

• Algorithm: Try mergin similar factors and see if that reduces

the encoding length

APPLICATION: FACT DISCOVERY

• Input: noun phrase–verbal phrase–noun phrase triples
• Non-disambiguated
• E.g. from OpenIE
• Goal: Find the facts (entity–relation–entity triples) underlying

the observed data and mappings from surface forms to entities and relations

CONNECTION TO BOOLEAN TENSORS

• We should see an np1–vp–np2 triple if
• there exists at least one fact e1–r–e2 such that
• np1 is the surface form of e1
• vp is the surface form of r
• np2 is the surface form of e2

CONNECTION TO BOOLEAN TENSORS

• What we want is Boolean Tucker3 decomposition
• Core tensor contains the facts
• Factors contain the mappings from entities and relations to

surface forms

xijk ≈

P

_

p=1 Q

_

q=1 R

_

r=1

gpqraipbjqckr

PROS & CONS

• Pros: Naturally sparse core tensor
• Core will be huge ⇒ must be sparse
• Natural interpretation
• Cons: No levels of certainity
• Either is or not
• Can only handle binary data

EXAMPLE RESULT

Subject: claude de lorimier, de lorimier, louis, jean-baptiste Relation: was born, [[det]] born in Object: borough of lachine, villa st. pierre, lachine quebec

39,500-by-8,000-by-21,000 tensor with 804 000non-zeros

CONCLUSIONS

• Boolean factorizations are more combinatorial in their flavour
• Interpretations as sets or graphs
• Boolean matrix factorization is computationally harder than

most normal factorizations

• With tensors the difference is not so big

FUTURE DIRECTIONS

• When should one apply Boolean factorizations?
• More education is needed
• Better algorithms & implementations
• I’ve been asking for this for 7 years now…
