BI-DIRECTIONAL FLOW PROVERS

TRUTH IN MEASUREMENT WITH DIRECT TRACEABILITY TO INTERNATIONALLY ACCEPTED STANDARDS

slide-3
SLIDE 3

WHAT IS A PROVER? An open or closed vessel of known volume that is used as a volumetric reference standard for the calibration of meters in liquid petroleum service. – API Chapter 4 Section 1

slide-4
SLIDE 4

WHAT IS ITS PURPOSE? In order to eliminate bias, the calibrated volume of a prover is used to determine a meter factor.

slide-5
SLIDE 5

WHAT IS METER FACTOR?

A meter factor is the ratio obtained by dividing the actual volume proven by the indicated volume registered by the meter. – API Chapter 4

Note: Factors that can influence the meter’s meter factor are flow rate, temperature, viscosity, wear, and contamination. Proving conditions should match operating conditions in order to maintain the most accurate results possible.

Meter Factor =

Prover Volume Meter’s Indicated Volume

_________________

slide-6
SLIDE 6

BI-DIRECTIONAL PROVER

Launch Chamber Sphere Displacer Detector Switch Four-Way Valve Valve Actuator Detector Switch Receiving Chamber

slide-7
SLIDE 7

PROVER DESIGN REQUIREMENTS

  • Pipe Size, Schedule & Flange Rating
  • Sphere Displacer Velocity
  • Volume Between Detector Switches
  • Four-Way Valve Sizing
  • Four-Way Valve Actuator
  • Pre-Run Length
slide-8
SLIDE 8

SPHERE DISPLACER VELOCITY

Note: Minimum Velocity to be no less than 0.5 fps

  • Max. V =

BPH x 0.286 (I.D. [in])

___________

2

< 5.0 fps _

=

Example:

  • Max. Flow Rate = 3,960 BPH

Pipe Diameter = 16”

  • Max. V = 3,960 x 0.286

(16)

2

= 4.42 fps

slide-9
SLIDE 9

PROVER VOLUME

  • Pre-run length
  • Distance (volume) between detector switches

Pre-Run Length Distance between Detector Switches

slide-10
SLIDE 10

LENGTH BETWEEN DETECTORS

  • In order to maintain an

uncertainty of +0.01%, at least 10,000 meter pulses should be collected between detector switches.

Distance between Detector Switches

Example:

Meter K-Factor = 2,000 pulses/bbl

  • Min. volume to achieve 10,000 pulses (VBS) = 210 gallons

Measuring section pipe inside diameter = 16” Pipe cross sectional area (A) = 1.396 ft Distance between detector switches (VBS/A) = 20.11 ft.

2

slide-11
SLIDE 11

FOUR-WAY VALVE SIZING

slide-12
SLIDE 12

FOUR-WAY VALVE SIZING

Example:

  • Max. Flow Rate = 3,960 BPH

Pipe Diameter = 10”

  • Max. V =

BPH x 0.286 (I.D. [in])

2

< 15.0 fps _

=

  • Max. V = 3,960 x 0.286

(16)

2

= 11.33 fps

slide-13
SLIDE 13

FOUR-WAY VALVE ACTUATOR

  • Mechanical
  • Electrical
  • Hydraulic

Note: The actuator is sized to maintain a reasonable Four-way valve cycle time,

  • r Closed to Closed time

(T c-c). This will be used to determine the required prover pre-run length.

slide-14
SLIDE 14

LENGTH OF PRE-RUN (RP) T

C-­‑C ¡

( )

RP=

___

2 + 2 1 SEC x Max V

__

Pre-Run Length

slide-15
SLIDE 15

LENGTH OF PRE-RUN (RP) T

C-­‑C ¡

( )

RP=

___

Example: Actuator Speed (T c-c) = 4.9 Seconds Sphere Velocity (Max V) = 4.42 fps

2 + 2 1 SEC x Max V

RP=

( )

+ 2

__ SEC x 4.42

1 4.9 2

___

= 13.03 ft

__

slide-16
SLIDE 16

LENGTH OF PRE-RUN (RP)

RP=

Pre-Run Length

13.03 ft
