Beyond Unit Testing Steve Loughran Julio Guijarro HP Laboratories, Bristol, UK steve.loughran at hpl.hp.com julio.guijarro at hpl.hp.com About Us Julio Guij arro Research scientist at HP Laboratories on Grid-S cale Deployment Leads t

slide-1
SLIDE 1

Steve Loughran Julio Guijarro HP Laboratories, Bristol, UK

Beyond Unit Testing

steve.loughran at hpl.hp.com julio.guijarro at hpl.hp.com

slide-2
SLIDE 2

2

About Us

Julio Guij arro

Research scientist at HP Laboratories on

Grid-S cale Deployment Leads t he S mart Frog open source effort

S t eve Loughran

Research scientist at HP Laboratories on

Grid-S cale Deployment

Apache Ant & Axis committer Co-author of

Java Development wit h Ant

Behind schedule on the 2nd edition

slide-3
SLIDE 3

two different distributed systems

Multi-tier webapp CERN Large Hadron Collider

slide-4
SLIDE 4

How do you show it works?

  • Europe's high-end server farms
  • Years of simulations
  • Nobel Prize winners, Computer

Scientists and physics PhD students

  • An old laptop nobody wants
  • Any spare time before you ship
  • You
slide-5
SLIDE 5

5

Classic unit tests

  • Run in a test harness
  • Don’t stress the system
  • Don’t run on real

servers

  • Don't run with real data
slide-6
SLIDE 6

6

Write less Unit Tests!

A modest proposal

slide-7
SLIDE 7

7

Apply Formal Methods!

  • Integrating Formal Met hods with XP development.
  • How to use axiomat ic t heorem proofs to verify

correctness in a large-scale distributed system.

  • How Milner's π-calculus is the underpinnings for the

BPEL workflow language.

  • Cont inuat ions vs. bisimilar st at e machines -which is

better for correctness proofs?

  • How relaxing your concurrency const raint s results in

higher throughput.

slide-8
SLIDE 8

8

Or: System Testing

slide-9
SLIDE 9

9

System Tests

  • Deploy the app
  • Add a real dataset
  • Use the app server
  • Remotely test from
  • ther sites/hosts
  • Test in the client
  • Are big, complex and

distributed

slide-10
SLIDE 10

10

How to test big systems

  • Simulate the production system.
  • Automate deployment
  • Write functional tests
  • Remote test from clients
slide-11
SLIDE 11

11

Embrace Virtualization

  • VMWare player free; workstation for $£€
  • Create VM images that resemble

production configurations.

  • Deploy and test into virtual machines
  • Host continuous integration server in VMs
  • Simulate complex/broken networks

S imulat e t he product ion syst em Automate deployment Write functional tests Remote test from clients

slide-12
SLIDE 12

12

…and become a cluster admin

  • PXE System Installers: linuxcoe.sf.net
  • Auto-rollback images during test and production
  • Isolate insecure platforms on virtual network
slide-13
SLIDE 13

13

Automate app deployment

  • RPM/APT/.msi packages pushed out to hosts
  • S

mart Frog: http://smartfrog.org/

  • Cargo: http://cargo.codehaus.org
  • Shell Scripts
  • Ant build files using scp, ssh

Simulate the production system Aut omat e deployment Write functional tests Remote test from clients

slide-14
SLIDE 14

14

Database setup

  • Data setup is too time consuming to do every test
  • Use the same DB that production will have.
  • Automated set up of the database
  • keep this DB snapshot and revert to it after a run.

(or the entire virtual machine image)

<mysql-admin> CREATE DATABASE diary; GRANT ALL PRIVILEGES ON diary.* TO 'diary'@'localhost'; SET PASSWORD FOR 'diary'@'localhost' = PASSWORD('${mysql.diary.pass}'); </mysql-admin>

slide-15
SLIDE 15

15

What to test?

  • system health tests
  • In-container unit tests
  • Remote web service/HTML tests
  • In-browser GUI testing
  • Load tests
  • Network failure simulations

…

Simulate the production system Automate deployment Writ e funct ional t est s Remote test from clients

slide-16
SLIDE 16

16

Health Test: “happy pages”

<waitfor maxwait="30" maxwaitunit="second" timeoutproperty="unhappy"> <http url="http://server/happyaxis.jsp"/> </waitfor> <fail if="unhappy"/> <%@ taglib uri="/WEB-INF/diary.tld" prefix="h" %> <body> <ha:happy classMustExist="org.jdom.JDOMException" errorText="JDom missing"/> We are happy </body> </html>

Delegate to machines:

slide-17
SLIDE 17

17

Test in-container with cactus

http://jakarta.apache.org/cactus/

Simulate the production system Automate deployment Writ e funct ional t est s Remote test from clients

slide-18
SLIDE 18

18

Cactus Test Case

http://jakarta.apache.org/cactus/

public class CactusPersistTest extends ServletTestCase { private static int counter = 0; private SessionFactory factory; public void testPersist() throws Exception { Event event = createTestEvent(); Session session = factory.openSession(); try { session.persist(event); } finally { session.close(); } assertEventIsInDB(event); } }

Simulate the production system Automate deployment Writ e funct ional t est s Remote test from clients

slide-19
SLIDE 19

19

<cactus> task choreographs

http://jakarta.apache.org/cactus/

<cactus:cactus warfile="${cactus.war}" errorProperty="cactus.failed" failureProperty="cactus.failed"> <containerset> <generic name="server" port="8080"> <startup> <copy file="${cactus.war}" tofile="${cactus.destfile}"

  • verwrite="true"/>

</startup> <shutdown> <delete file="${cactus.destfile}"/> </shutdown> </generic> </containerset> <classpath><path refid="test.classpath"/></classpath> <formatter type="xml"/> <batchtest todir="${test.data.dir}"> <fileset dir="test" includes="**/*Test.java"> </batchtest> </cactus:cactus>

Simulate the production system Automate deployment Writ e funct ional t est s Remote test from clients

slide-20
SLIDE 20

20

Cactus Demo

− Needs classpath right for client and server − cactus servlet is possible security risk

http://jakarta.apache.org/cactus/

slide-21
SLIDE 21

21

GUI testing hurts

  • Static HTML is the easiest (HttpUnit)
  • Swing, DHTML, SWT, Flash hard.
  • Most people stop at the “model”
  • Whoever does a new GUI -fix this!

Simulate the production system Automate deployment Writ e funct ional t est s Remote test from clients

slide-22
SLIDE 22

22

jsUnit is JUnit for JavaScript

http://www.jsunit.net/

function test3() { var buffer = top.testManager.documentLoader.buffer(); var emps = buffer.document.getElementsByTagName('employee'); assert('expected 5 employees, not ' + emps.length, emps.length == 5); var empid = emps[0].getElementsByTagName('employeeId'); assert('employeeId[0] was ' + empid[0].firstChild.data, empid[0].firstChild.data == 'EMP0001'); }

slide-23
SLIDE 23

23

Selenium: tests in a table

http://www.openqa.org/selenium/

<tr> <td>verifyTitle</td> <td>Click Page Target</td> <td>&nbsp;</td> </tr>

slide-24
SLIDE 24

24

WS Interop Testing

  • Use the real client API/classes
  • Pass down URLs via system properties
  • Test different endpoints in parallel processes
  • Include timeouts; proxy support
  • Log for blame assignment

protected String getOption(String property, boolean required) { String option = System.getProperty(property); if (required && option== null) { fail("No property " + property); } return option; }

ex: http://deployapi.iseran.com:8080/logs/

Simulate the production system Automate deployment Write functional tests Remot e t est from client s

slide-25
SLIDE 25

25

Distributed Testing

  • Allocate & configure test systems
  • Deploy application across nodes
  • Deploy tests on other nodes
  • Collect and correlate results
  • Try to understand what went wrong

Simulate the production system Automate deployment Write functional tests Remot e t est from client s

slide-26
SLIDE 26

26

SmartFrog

A framework for describing, deploying and managing distributed service components.

HttpUnitTests extends JUnitTestSuite { package "d1.webapp.test"; name "HttpUnitTests"; server.url TBD; sfProcessHost "client"; properties [ ["server.url",server.url], ["cactus.contextURL",server.url] ]; classes [ "EventFeedTest", "HappyTagTest", "IndexTest" ]; }

http://smartfrog.org/

  • SmartFrog daemon
slide-27
SLIDE 27

27

Distributed Deployment of App & JUnit

  • SmartFrog daemon
slide-28
SLIDE 28

28

XHTML output of test results

− no x-system summary − no merging of logs from different systems − no notification + ~live output + log capture

slide-29
SLIDE 29

29

Future GUI? GridUnit

http://gridunit.sourceforge.net/

  • Swing GUI for testing on

OurGrid

  • Unit test across many

different machines

  • But not (yet) distributed

applications

  • Aggregate view of results
  • “partial” success
  • Common JUnit wire format
slide-30
SLIDE 30

30

Call to Action

  • Focus on system tests
  • Embrace Virtualization: VMWare, Xen
  • Use Cactus for in-container testing
  • Use Selenium/jsUnit for browser tests
  • Join us in distributed system testing
slide-31
SLIDE 31

31

Junit4?

  • Java5 only
  • Extension tools not there yet
  • Integration with Ant, Maven coming

along.

  • Ant 1.7 <junit> will work with junit4.jar
  • JUnit team plan their own task

(Ant team are working with them)
