Assessment of effective mAnAgement strAtegies for JApAnese knotweed

Tyler Jollimore (B.Sc. Agriculture, M.Sc. Candidate) Tyler.Jollimore.Knotweed@gmail.com Facebook: Japanese Knotweed Research Nova Scotia

1

Knotweed et al. – Weed Management by Tyler Jollimore

slide-2
SLIDE 2

Presentation outcomes

  • Improve understanding of Japanese knotweed (Fallopia japonica)

basic biology, and how it performs in native stands (e.g. in Japan)

  • Understand how the behavior of knotweed in environments

contributes to the decline of the ecosystem and ecosystem services

  • Critically think about the applicability of these studies in your own

dealings with knotweed

  • Understand the importance of managing knotweed safely and

effectively

2

slide-3
SLIDE 3

What is an invasive species

  • An organism from an exotic area that causes

damage to the: environment, economy or human health

4

Purple Loosestrife Japanese knotweed, near a composting toilet

slide-4
SLIDE 4

From Japan to Nova Scotia – How different does it look?

6

Child & Wade (2000) Japanese knotweed on Mount Fuji, Japan.

  • Primary colonizer of

volcanic slopes

  • Helps stabilize soil

aggregates

  • Attracts other plant

species to the area, allows succession to proceed, building an ecosystem

slide-5
SLIDE 5

From Japan to Nova S Scoti tia – How different does it look?

7

slide-6
SLIDE 6

Japanese knotweed – The Big Plant

  • Introduced to North America and Europe

from Japan during the 1800s

  • Initially used for horticulture, property

boundaries, dune stabilization* and ‘it was pretty’

  • Fell out of favor around the 1920s when

the problems associated with it became more publicly known (Townsend 1997)

8

Japanese knotweed emerging in Spring, looks like bamboo

slide-7
SLIDE 7

9

  • A. Fletcher 2013 – Sigmoid Curve

Area Occupied Time

Initial Introduction Adaptation Wide Spread Public Awareness Proliferation We are here

slide-8
SLIDE 8

10

Polycarpic Herbaceous Rhizomatous Perennial

slide-9
SLIDE 9

Growth & development

  • Reaches peak height of 200-300 cm

by middle of June

  • Self pruning canopy
  • Flowers in mid-July into August
  • Seed set around October

11

slide-10
SLIDE 10

Reproduction

  • Thought to only produce

asexually in Nova Scotia (Larsen 2013)

  • Spread by rhizomes and

nodular stems (De Waal 2001)

  • While seeds are always

produced in NS, none are viable (Larsen 2013)

12 Knotweed stem Knotweed ‘seed’ (non-viable) x 50 magnification

slide-11
SLIDE 11

Problematic characteristics

  • Rapid growth early in the

growing season

13

slide-12
SLIDE 12

14

See ya later bud!

slide-13
SLIDE 13

15 South Maitland, NS May 8 2017 May 24 2017 Around 175 cm

  • South Maitland, around 660 m2 of

knotweed

slide-14
SLIDE 14

16

June 18 2017

  • T. Jollimore

~300+ cm

slide-15
SLIDE 15

Problematic characteristics

  • Tall canopy limits light transmission to

shorter native plants

17

slide-16
SLIDE 16

Problematic characteristics

  • Rapid growth early in the growing

season

  • Tall canopy limits light transmission

to shorter native plants

  • High stem density

18

slide-17
SLIDE 17

19

This is not normal… for riparian zones: average stem density in plots is 30 – 40 stems

slide-18
SLIDE 18

Its problematic characteristics lead to

  • Environmental consequences: accelerated soil erosion, reduced

native plant species, increased risk of flooding (and intensity), interference with infrastructure, displacement of some seabird species*, super-pollination

  • Economic consequences: reduced value of real-estate, damage to

building foundations, block access to water ways

  • Human cost: stress, uncertainty of management plans + cost

(expensive to deal with on large scale)

20

slide-19
SLIDE 19

Native plant displacement

  • Knotweed’s

dominant canopy causes native plants to struggle beneath it

  • This leaves bare soil

exposed…

21

  • S. White (2017) knotweed along the Rights River in Antigonish, NS
slide-20
SLIDE 20

Accelerated soil erosion + sediment loading

  • Knotweed roots not

good at holding soil

  • Plants such as grasses

can block sediment, but knotweed is out competing

  • Problematic near

rivers

22

slide-21
SLIDE 21

23

  • Elliot (2011) knotweed grew

through building foundation

  • 83% reduction in real estate

value in the UK

slide-22
SLIDE 22

Cost of large scale management

  • London Olympics (2012) ~$123 Million (Oliver 2011)
  • Large scale mechanical extractions, spot applications, membrane

bags, tissue incineration

  • Was successful, however some patches occasionally return
  • One-time management not practical, it is an on-going activity

24

slide-23
SLIDE 23

Where does it leave us

  • Massive ecological disruption if left unchallenged
  • Limited capability for individuals and organizations to control
  • Uncertainty about what management strategies will work
  • Biological control trials underway (Shaw et al., 2009); update from Dr.
  • R. Bourchier (AAFC/AAC) – still determining needs for the psyllid

26

slide-24
SLIDE 24

What needed to be done to go forward with management

  • Determine if mechanical control is worth the effort
  • Determine what herbicides are effective for control (glyphosate

efficacy compared to others)

  • Determine if any particular application method is more effective
  • What time during the growing season is best to conduct management

27

slide-25
SLIDE 25

Experiment setup

  • 1 x 1 m or 1 x 2 m plots were established, 2016 or 2017
  • Two locations for each experiment
  • Measured: density, height and diameter – when treatments were

applied and in fall

  • Most used ‘spot applications’ to apply herbicide (CO2 pressurized,

with nozzle) spray until leaves are wet

  • Treatments provide good control if they reduced density

significantly (P < 0.05) when compared to the control (e.g. from 30 to 5 – 0)

28

slide-26
SLIDE 26

29

Trade Name Active Ingredient Application Rate (g a.i. or a.e. L water-1) Surfactant Herbicide Group Control Do nothing

  • Arsenal Powerline

Imazapyr

12

  • 2

Milestone Aminopyralid

2.4 or 4.8

  • 4

Roundup Weathermax Glyphosate

9

  • 9

Truvist Aminocyclopyrachlor + Chlorosulfuron

1

2.5 mL Activ8+ L water-1 4

slide-27
SLIDE 27

Is mechanical control alone sufficient to control Japanese knotweed?

  • Experiment: Effect of repeated cutting
  • Hypothesis: repeatedly cutting

down knotweed will strain energy reserves and reduce stem density in the following growing season

  • 1) control, 2) cut once, 3) cut twice
  • Cutting at peak height, one month

after

30

slide-28
SLIDE 28

31

slide-29
SLIDE 29

32

slide-30
SLIDE 30

Does combining mechanical and chemical methods improve control?

  • Experiment: Main & interactive effects of cutting

and herbicide application

  • Hypothesis: application of cutting prior to

herbicide application, will improve susceptibility to herbicide activity, thus causing density reductions in the following growing season

  • 2x3 factorial, factors: cut (no, yes) and herb

(none, gly, amn)

33 Group 4 herbicide damage on Japanese knotweed

slide-31
SLIDE 31

34

slide-32
SLIDE 32

35

slide-33
SLIDE 33

36

No cut No herbicide Cut No herbicide

slide-34
SLIDE 34

37

No cut Milestone No cut Roundup Cut Roundup

slide-35
SLIDE 35

From this

  • Cutting alone only reduces height and diameter 1 YAT, density is not

always significantly reduced

  • Glyphosate and aminopyralid significantly reduced stem density when

spot applied to peak height growth or to regrowth, similar performance

  • Cutting prior to herbicide treatment does not improve management
  • utcomes but… may make it possible with large contiguous stands

38

slide-36
SLIDE 36

Does herbicide application method affect herbicide efficacy on Japanese knotweed?

  • Experiment: Comparison of spot sprays and

injections of herbicides

  • Hypothesis: spot sprays will cause more

significant reductions in knotweed stem density due to the greater quantity of active ingredient applied

  • Nested ANOVA design, five treatments:

untreated control, factors: herbicide (none, gly, amn) and method (spot, inject)

39 Glyphosate damage on Japanese knotweed

slide-37
SLIDE 37

40

slide-38
SLIDE 38

41

slide-39
SLIDE 39

42

slide-40
SLIDE 40

43

slide-41
SLIDE 41

We learned

  • Spot applications and injections of herbicides both reduce knotweed

stem density 1 YAT. However, injections seem to take a ‘little longer’ than the spot spray.

  • Use injections situationally where required, as significantly more work

is involved to perform treatments

44

slide-42
SLIDE 42

5) Does seasonal timing of herbicide application impact its ability to control knotweed?

  • Experiment: Effect of seasonal herbicide application

timing

  • Hypothesis: fall herbicide application will

have the greatest reduction in knotweed shoot density in the following growing season, as literature indicates carbohydrate translocation occurs heavily in the fall (Price et al 2002)

  • Two timings: peak height and fall
  • Control, imazapyr, aminopyralid,

glyphosate or aminocyclopyrachlor

46 Japanese knotweed frost damage in the fall

slide-43
SLIDE 43

PEAK HEIGHT

47

slide-44
SLIDE 44

48

slide-45
SLIDE 45

South Maitland

Antigonish

49

slide-46
SLIDE 46

50

Control Imazapyr Glyphosate

slide-47
SLIDE 47

FA FALL

51

slide-48
SLIDE 48

52

slide-49
SLIDE 49

53

slide-50
SLIDE 50

54

Glyphosate Aminopyralid

slide-51
SLIDE 51

Why does the fall timing change herbicide effectiveness?

  • Some physiological processes might be more impacted by herbicide

application and translocation at this time (bud formation, winter prep)

  • Price et al. (2002) indicated that ~90% of fixed carbon in knotweed

rhizomes is moved around this time. Worked out using radiotracer carbon (marked molecules)

  • Later in the growing season plants focus on bulking up carb reserves

in rhizomes

55

slide-52
SLIDE 52

56 Emergence Carbs from roots to vegetation Flowering Carbs from roots to vegetation (nectar production) Peak Height Carbs go back to roots Flower bud formation Carbs from roots to vegetation Seed set and senescence Carbs go down to roots to prepare for winter

slide-53
SLIDE 53

What did I learn?

  • Mechanical methods alone not adequate to control knotweed
  • Cutting prior to herbicide application does not improve control

achieved (does make application a little easier)

  • Application methods are equivalent in control provided, but vary in

difficulty

  • Peak height and fall herbicide application are both valid control

windows

57

slide-54
SLIDE 54

58

Near Glyphosate Plots Near Imazapyr plots Glyphosate Plots 2 YAT

slide-55
SLIDE 55

Herbicide options

  • Imazapyr works very well (at peak height and fall) however,

environmentally risky (uptake from roots and soil) – might be more useful near home foundations, or in aquatic scenarios (needs registration in Canada)

  • Glyphosate is available to consumers in Nova Scotia domestically

(anyone can buy it), similar in USA

  • Aminopyralid will be useful where some selectivity is required doesn’t

hurt grasses, could use to help restore an area with them

59

slide-56
SLIDE 56

1

60

Cut – Spray Regrowth Cut – Spray Regrowth Cut – Spray Regrowth Cut – Spray Regrowth Spray in Fall Spray in Fall Spray in Fall

slide-57
SLIDE 57

62 This CANNOT become the new normal It also doesn’t have to be…

slide-58
SLIDE 58

63

SEPTE TEMBE BER 2 2018 SPRING 2019 2019

Target Acquired

slide-59
SLIDE 59

64

Case Studies

  • 15 between: NS, NB, &

Mass.

  • Using domestically

available glyphosate in 1st year

  • Some injections where

needed

  • Results in Spring 2020
slide-60
SLIDE 60

While I’m in the neighborhood

  • If you’ve got a knotweed in the area you would like checked out

please get in touch!

  • Would be thrilled to do some case studies in USA
  • Between: Detroit, St. Josephs and Kalamazoo

65

slide-61
SLIDE 61

For more information

  • tyler.jollimore.knotweed@gmail.com
  • Facebook: Japanese Knotweed

Research, Nova Scotia

  • Knotweed et al. - Weed Management

by Tyler Jollimore

  • Cell: 1-902-880-8207, call or text!

66

slide-62
SLIDE 62

Acknowledgements

  • Supervisor: Scott White, Dalhousie Faculty of Agriculture
  • The Stewardship Network for having me!
  • Department of Transportation and Infrastructure Renewal for funding

this work

  • Morgan McNeil and other graduate student support

67

slide-63
SLIDE 63

Citations

  • Anon (2018). Japanese knotweed encroaching on my home in East Chezzicook. Personal

Communication

  • De Waal, ,L.C. (2001). A viability study of fallopia japonica stem tissue. Weed Research, 41(5), 447-

460.

  • Elliot, V. (2011). Couple are forced to demolish their £300k four-bed home after it was invaded by

japanese knotweed. Retrieved 01/08, 2018, from http://www.dailymail.co.uk/news/article- 2052337/Hertfordshire-couple-demolish-300k-home-rid-Japanese-knotweed.html

  • H. Hudson, 2018 Knotweed flowering in Michigan, USA
  • Larsen, T. (2013). Biology, ecological impacts, and management of japanese knotweed

(polygonum cuspidatum syn. fallopia japonica) in nova scotia.

  • Townsend, A. (1997). Japanese knotweed: A reputation lost. Arnoldia, 57(3), 13-19
  • Price, E. A., Gamble, R., Williams, G. G., & Marshall, C. (2002). Seasonal patterns of partitioning

and remobilization of 14 C in the invasive rhizomatous perennial japanese knotweed (fallopia japonica (houtt.) ronse decraene). Ecology and evolutionary biology of clonal plants (pp. 125-140) Springer.

68

slide-64
SLIDE 64

69

slide-65
SLIDE 65

70

House in East Chezzicook - 2018
