Aims and Objectives Requires some basic knowledge of clinical examinations Clinical examination station (OSCE) One way to prepare: Retrospective approach Cardiovascular examination: 2 cases Respiratory examination: 2

slide-1
SLIDE 1
slide-2
SLIDE 2
  • Requires some basic knowledge of clinical examinations
  • Clinical examination station (OSCE)
  • One way to prepare: ‘Retrospective approach’
  • Cardiovascular examination: 2 cases
  • Respiratory examination: 2 cases
  • Duration: 70 mins
  • Slides and recordings: www.bitemedicine.com/watch
  • Other common OSCE cases available in previous and upcoming webinars
  • Aim of the week is to cover most of the common scenarios

2

Aims and Objectives

slide-3
SLIDE 3

3

Clinical examination station: how to prepare?

EXAMINATION ROUTINE PRESENTATION VIVA

  • Perform each step of the

routine confidently

  • Pick up on signs
  • Present findings

systematically

  • List appropriate

differentials based on findings

  • Answer questions

systematically

  • Explain your thinking

‘Retrospective approach’

  • 1. Formulate an OSCE Cases List
  • 2. Prepare your ‘VIVA’ for those cases
  • Positive signs of diagnosis
  • ‘Typical’ findings presentation
  • Risk factors
  • Signs of decompensation
  • List of differentials
  • Complications
  • How would you investigate this patient?
  • How would you manage this patient?
slide-4
SLIDE 4

4

Clinical examination station: how to prepare?

‘Retrospective approach’

  • 3. Finalise your examination routine
  • Each step of the routine
  • Signs you are looking for
  • Your speech
  • 4. Practice your examination routine
  • n friends
  • 5. Go to the wards/clinics looking for

your cases

EXAMINATION ROUTINE PRESENTATION VIVA

  • Perform each step of the

routine confidently

  • Pick up on signs
  • Present findings

systematically

  • List appropriate

differentials based on findings

  • Answer questions

systematically

  • Explain your thinking
slide-5
SLIDE 5

What cases could come up?

1. Mitral regurgitation 2. Aortic stenosis 3. Prosthetic heart valves: aortic, mitral or both 4. Stable chronic heart failure 5. Ischaemic heart disease: CABG scars

This is not a definitive list

  • But by preparing for these you will be better at:
  • Your exam routine
  • Looking out for important signs
  • Formulating your findings systematically
  • Tackling the VIVA

5

Cardiovascular examination: OSCE Cases list

slide-6
SLIDE 6

I performed a cardiovascular examination on this patient

  • Who has signs suggestive of mitral regurgitation

My main positive findings are: 1. XXX 2. YYY My relevant negative findings are: 1. XXX (Risk factors) 2. YYY (Signs of decompensation) 3. ZZZ (POSSIBLE associated features) Overall, this points towards a diagnosis of mitral regurgitation with no signs of decompensation

6

How to present your findings?

If you have an idea, then back yourself from the start. It gets the examiner listening RELEVANT negatives 99% of the time your patient will be STABLE

slide-7
SLIDE 7

Peripheral Pulse

  • Irregularly irregular

7

Cardiovascular examination: Case 1

Central Auscultation

  • Pansystolic murmur
  • Loudest at the mitral region
  • Exacerbated
  • n

patient lying

  • n

their L side and on held expiration

  • Radiation to axilla
slide-8
SLIDE 8

8

Question 1

slide-9
SLIDE 9

9

Cardiovascular examination: Case 1 – Mitral regurgitation

What is a pan-systolic murmur?

  • Lasts entire duration between S1 & S2
  • Does not change in intensity
slide-10
SLIDE 10

10

Cardiovascular examination: Case 1 – Mitral regurgitation

What is a pan-systolic murmur?

  • Lasts entire duration between S1 & S2
  • Does not change in intensity
slide-11
SLIDE 11

11

Cardiovascular examination: Case 1 – Mitral regurgitation

Why is mitral regurgitation associated with an irregularly irregular pulse?

  • Mitral regurgitation = MV valve doesn't close

properly

(1)

slide-12
SLIDE 12

12

Cardiovascular examination: Case 1 – Mitral regurgitation

Why is mitral regurgitation associated with an irregularly irregular pulse?

  • Mitral regurgitation = MV valve doesn’t close

properly

  • So when the LV starts to contract, blood is

regurgitated from the LV back into the LA

(1)

slide-13
SLIDE 13

13

Cardiovascular examination: Case 1 – Mitral regurgitation

Why is mitral regurgitation associated with an irregularly irregular pulse?

  • Mitral regurgitation = MV valve doesn’t close

properly

  • So when the LV starts to contract, some blood is

regurgitated from the LV back into the LA

  • Over time, LA becomes dilated

(1)

slide-14
SLIDE 14

14

Cardiovascular examination: Case 1 – Mitral regurgitation

Why is mitral regurgitation associated with an irregularly irregular pulse?

  • Mitral regurgitation = MV valve doesn’t close

properly

  • So when the LV starts to contract, some blood is

regurgitated from the LV back into the LA

  • Over time, LA becomes dilated à LA starts to

remodel à affects the electrical conduction

  • This leads to atrial fibrillation (irregularly irregular

pulse) Summary: In chronic MR, the L atrium remodels à this affects electrical conduction through the heart

(1)

slide-15
SLIDE 15

15

Cardiovascular examination: Case 1 – Mitral regurgitation

Please present your findings?

I performed a cardiovascular examination on this patient who has signs suggestive of MITRAL REGURIGTATION My main positive findings are:

  • I palpated an irregularly, irregular pulse, suggestive of atrial fibrillation
  • On auscultation, I could hear normal 1st & 2nd heart sounds with a systolic murmur between S1

& S2

  • The systolic murmur was:
  • Character: pansystolic
  • Region: loudest over the mitral region
  • Augmentation: end-expiration with the patient lying on their left side
  • Radiation: axilla
slide-16
SLIDE 16

16

Cardiovascular examination: Case 1 – Mitral regurgitation

Please present your findings?

My relevant negative findings are:

  • No signs of vascular risk factors e.g. tar staining, tendon xanthomata
  • No peripheral stigmata of infective endocarditis
  • No scars to suggest coronary artery bypass graft or valve replacement
  • No signs of decompensation e.g. pulmonary or peripheral oedema

This points towards a diagnosis of grade 3 mitral regurgitation complicated by atrial fibrillation

slide-17
SLIDE 17

17

Cardiovascular examination: Case 1 – Mitral regurgitation

What are your differentials?

1. Mitral regurgitation

  • 2. Aortic stenosis
  • Ejection systolic murmur with radiation to carotids
  • 3. Tricuspid regurgitation
  • Pansystolic murmur
  • Heard loudest over lower L sternal edge
  • Augmented on held INSPIRATION
  • No radiation
  • Rarer

Acute Chronic Infective endocarditis Ischaemic injury to L ventricle à dilated MV annulus Rupture of papillary muscle (e.g. post MI) Calcification of MV annulus Rheumatic heart disease

slide-18
SLIDE 18

18

Cardiovascular examination: Case 1 – Mitral Regurgitation

What are possible complications of mitral regurgitation

Complications from the valve

  • Infective endocarditis

Complications from impaired outflow

  • Left ventricular failure
  • Atrial fibrillation
slide-19
SLIDE 19

19

Cardiovascular examination: Case 1 – Mitral regurgitation

How would you investigate this patient?

Bedside

  • Basics observations: HR, BP, RR, SpO2
  • Urine dip: glycosuria for diabetes
  • ECG:
  • AF
  • P-mitrale (broad, notched P waves): sign of dilated LA

Bloods

  • Inflammatory markers: CRP and ESR for infective

endocarditis

  • BNP: raised if associated heart failure

(2)

slide-20
SLIDE 20

20

Cardiovascular examination: Case 1 – Mitral regurgitation

How would you investigate this patient?

Imaging

  • CXR
  • L atrial enlargement
  • Signs of heart failure (ABCDE)
  • ECHO: gold standard test to diagnose & assess severity
  • Severe: Jet width > 0.7cm, regurgitant volume >

60mls Special

  • Coronary angiography: measure gradient across valve

and assess for concomitant coronary artery disease

(3)

slide-21
SLIDE 21

21

Cardiovascular examination: Case 1 – Mitral regurgitation

How would you manage this patient?

Conservative

  • Improve cardiovascular risk factors e.g. smoking cessation

Medical

  • Anticoagulation for AF
  • Manage heart failure if present
  • ACEi, beta-blockers, diuretics

Surgical

  • Valve repair or replacement indicated if:
  • Symptomatic
  • Severe LV dilation
  • Significantly reduced LVEF
  • New-onset AF
slide-22
SLIDE 22

22

Grading murmurs

Freeman & Levine Grading for heart murmurs

  • Grade 1: Faintest murmur
  • Grade 2: Faint murmur
  • Grade 3: Loud murmur, no thrill
  • Grade 4: Loud murmur + palpable thrill
  • Grade 5: Murmur heard with stethoscope partially on chest + thrill
  • Grade 6: Murmur heard with stethoscope held off chest
slide-23
SLIDE 23

Peripheral

23

Cardiovascular examination: Case 2

Central Auscultation

  • Bibasal crackles

(4) (5) (6)

slide-24
SLIDE 24

24

Question 2

slide-25
SLIDE 25

25

Cardiovascular examination: Case 2 – Congestive cardiac failure

Please present your findings?

I performed a cardiovascular examination on this patient who has signs suggestive of CHRONIC HEART FAILURE My main positive findings are:

  • Tar staining
  • Finger prick marks suggesting blood glucose monitoring
  • Peripheral oedema up to knees
  • I also noticed a vertical 6cm scar on the neck along the distribution of the carotid artery

suggestive of a carotid endarterectomy scar

  • On auscultation of the lung bases: bibasal crackles
slide-26
SLIDE 26

26

Cardiovascular examination: Case 2 – Congestive cardiac failure

Please present your findings?

My relevant negative findings are:

  • No scars to suggest coronary artery bypass graft or valve replacement
  • Normal heart sounds, with no added sounds or murmurs
  • No peripheral stigmata of infective endocarditis

This points towards congestive cardiac failure

  • The presence of both pulmonary and peripheral oedema suggests an element of

decompensation

slide-27
SLIDE 27

27

Cardiovascular examination: Case 2 – Congestive cardiac failure

What are the possible causes of heart failure?

  • Heart failure is defined as inadequate cardiac output for the body’s

requirements

  • Can be classified as L or R sided heart failure

Left sided Right sided Ischaemic heart disease Left sided heart failure Valvular disease

  • Mitral
  • Aortic

Valvular disease

  • Tricuspid
  • Pulmonary

Cor pulmonale

  • COPD
  • Fibrosis
  • PE
  • Obstructive sleep apnoea
slide-28
SLIDE 28

28

Cardiovascular examination: Case 2 – Congestive cardiac failure

How would you investigate this patient?

Bedside

  • Basics observations: HR, BP, RR, SpO2
  • ECG: L ventricular strain (LBBB and large amplitude QRS) or R ventricular

strain (RBBB and right axis) Bloods

  • FBC: anaemia (causes or exacerbates heart failure)
  • BNP or NT-pro BNP
  • U&Es: renal function can be deranged in heart failure (cardiorenal

syndrome)

  • Screen for risk factors: diabetes, lipids
slide-29
SLIDE 29

29

Cardiovascular examination: Case 2 – Congestive cardiac failure

How would you investigate this patient?

Imaging

  • CXR
  • ABCDE signs of heart failure
  • ECHO: gold standard test to diagnose & assess severity
  • Assess left ventricular ejection fraction

(3)

slide-30
SLIDE 30

30

Cardiovascular examination: Case 2 – Congestive cardiac failure

How would manage CCF?

MDT approach: GP, heart failure team (cardiologist, specialist nurses), occupational therpaist Conservative

  • Stop smoking and diabetes control
  • Healthy diet and consider fluid restriction
  • Regular exercise

Medical

  • 1st line: Beta blocker and ACEi
  • Add furosemide if evidence of fluid overload, as is the case here
  • 2nd line: add in aldosterone antagonist
  • 3rd line: consider cardiac resynchronisation therapy or implantable cardiac defibrillator

Surgery

  • Heart transplant
  • Left ventricular assist device
  • Given to patients unlikely to survive until heart donor becomes available
slide-31
SLIDE 31

31

Cardiovascular examination: Case 2 – Congestive cardiac failure

New York Classification of heart failure

Grading Symptoms Grade 1 No SOB Grade 2 SOB with exertion

  • Slight limitation of physical activity

Grade 3 SOB with exertion

  • Marked limitation of physical activity
  • Mild activity causes symptoms

Grade 4 SOB at rest

slide-32
SLIDE 32

What cases could come up?

1. Surgical: Lobectomy/Pneumonectomy 2. Pulmonary fibrosis 3. Bronchiectasis 4. COPD 5. Pleural effusion 6. Lung malignancy

32

Respiratory examination: OSCE Cases list

slide-33
SLIDE 33

Peripheral

33

Respiratory examination: Case 1

Central End of the bed:

  • Audible wet cough from the end of

the bed Auscultation:

  • Coarse crackles which change on

coughing

  • Occasional wheeze

(7) (8)

slide-34
SLIDE 34

34

Question 3

slide-35
SLIDE 35

35

Respiratory examination: Case 1 – Bronchiectasis

Please present your findings?

I performed a respiratory examination on this gentleman who has signs of BRONCHIECTASIS My main positive findings are:

  • Audible productive cough
  • Long acting anti-muscarinic inhaler at the bedside
  • Digital clubbing
  • On auscultation:
  • Coarse crepitation's that altered on coughing
slide-36
SLIDE 36

36

Respiratory examination: Case 1 – Bronchiectasis

Please present your findings?

My relevant negative findings are:

  • Reassuringly, not requiring oxygen currently
  • No CO2 retention flap
  • No signs of decompensation (e.g. cor pulmonale – raised JVP and peripheral oedema)

This points towards a diagnosis of bronchiectasis

  • The patient displayed no evident signs of an underlying cause e.g. rheumatoid arthritis
  • The commonest causes of bronchiectasis are idiopathic and post-infection, which I

suspect may well be the case in this patient

slide-37
SLIDE 37

37

Respiratory examination: Case 1 – Bronchiectasis

(9)

slide-38
SLIDE 38

38

Question 4

slide-39
SLIDE 39

39

Respiratory examination: Case 1 – Bronchiectasis

What are the possible causes of bronchiectasis

Cause Examples Congenital Cystic fibrosis Kartgener’s syndrome Primary ciliary dyskinesia Yellow nail syndrome Post-infection Measles TB Aspiration Immunological dysfunction Rheumatoid arthritis Inflammatory bowel disease ABPA Hypogammaglobulinemia

slide-40
SLIDE 40

40

Respiratory examination: Case 1 – Bronchiectasis

What are the differentials?

  • Bronchiectasis: think of possible causes
  • Fibrosis

Bronchiectasis Fibrosis Productive cough (Sputum pot) Dry cough Coarse crackles which change on coughing Fine end-inspiratory crackles

slide-41
SLIDE 41

41

Respiratory examination: Case 1 – Bronchiectasis

Cardiology Respiratory Abdominal Infective endocarditis Cyanotic heart disease Atrial myxoma Abscess Bronchiectasis Cancer Definitely not COPD Empyema Fibrosis Inflammatory bowel disease Coeliac disease Chronic liver disease

What are the respiratory causes of clubbing?

slide-42
SLIDE 42

42

Respiratory examination: Case 1 – Bronchiectasis

How would you investigate this patient?

Bedside

  • Basic obs: HR, BP, RR, SpO2
  • Sputum MCS: screen for infection or colonisation
  • H.influenzae and P.aeruginosa

Bloods

  • FBC and CRP: evidence of infection
  • ABG: respiratory failure
slide-43
SLIDE 43

43

Respiratory examination: Case 1 – Bronchiectasis

How would you investigate this patient?

Imaging

  • CXR: tramlines and ring shadows
  • CT thorax: signet ring sign

Special tests

  • Spirometry: obstructive pattern with FEV1/FVC < 0.7
  • Screen for underlying aetiology: RF, immunoglobulins, sweat test

Restrictive Obstructive FEV1

  • r ↓

↓ FVC ↓ FEV1/FVC >70% <70%

slide-44
SLIDE 44

44

Respiratory examination: Case 1 – Bronchiectasis

(10)

slide-45
SLIDE 45

45

Respiratory examination: Case 1 – Bronchiectasis

(11)

slide-46
SLIDE 46

46

Respiratory examination: Case 1 – Bronchiectasis

How would you treat this patient?

MDT approach: respiratory team, GP, occupational therapists Conservative

  • Pulmonary rehabilitation
  • Immunisations

Medical

  • Bronchodilators and/or inhaled corticosteroids
  • Long-term antibiotics: azithromycin
  • Mucolytics

Surgical

  • Lobectomy
  • Lung transplantation
slide-47
SLIDE 47

Peripheral

  • Fine tremor

47

Respiratory examination: Case 2

Central

  • Reduced cricosternal distance
  • Hyper-resonant percussion
  • Global polyphonic wheeze

(9) (4)

slide-48
SLIDE 48

48

Question 5

slide-49
SLIDE 49

49

Respiratory examination: Case 2 – COPD

Please present your findings?

I performed a respiratory examination on this patient who has signs of chronic obstructive pulmonary disease My main positive findings are:

  • A fine tremor suggesting beta agonist use
  • Evidence of tar staining
  • A reduced cricosternal distance with hyper-resonant percussion suggesting lung

hyperexpansion

  • On auscultation, a global polyphonic wheeze
  • Pitting peripheral oedema suggesting cor pulmonale
slide-50
SLIDE 50

50

Respiratory examination: Case 2 – COPD

Please present your findings?

My relevant negative findings are:

  • No signs of mediastinal shift: central trachea, apex beat non-displaced
  • No signs of decompensation (no CO2 retention flap)
  • No signs of other treatment e.g. no supraclavicular scar (seen for surgery for

TB) This points towards chronic obstructive pulmonary disease

  • The patient has evidence of a smoking history which is the likely underlying

cause

  • He also has evidence of cor pulmonale
slide-51
SLIDE 51

51

Respiratory examination: Case 2 – COPD

What are the differentials?

  • COPD: think of possible causes
  • Elderly: smoking
  • Young: alpha-1-antitrypsin deficiency
  • Asthma

COPD Asthma Older patient + Evidence of smoking Younger patient +/- smoking Beta-agonists Anti-muscarinic Inhaled corticosteroids Beta-agonists Anti-muscarinics not used Inhaled corticosteroids

slide-52
SLIDE 52

52

Respiratory examination: Case 2 – COPD

How would you investigate this patient?

Bedside

  • Basic obs
  • Sputum MCS: screen for infection or colonisation
  • H.influenzae and S.pneumoninae
  • ECG: evidence of right heart failure e.g. RBBB and right axis

Bloods

  • FBC and CRP: evidence of infection
  • ABG: type 2 respiratory failure
  • Alpha-1-antitrypsin
slide-53
SLIDE 53

53

Respiratory examination: Case 2 – COPD

How would you investigate this patient?

Imaging

  • CXR: hyperexpansion +/- infection. CT not usually required
  • Echocardiogram: evidence of heart failure

Special tests

  • Spirometry: obstructive pattern with FEV1/FVC < 0.7

Restrictive Obstructive FEV1

  • r ↓

↓ FVC ↓ FEV1/FVC >70% <70%

(12)

slide-54
SLIDE 54

54

Question 6

slide-55
SLIDE 55

55

Respiratory examination: Case 2 – COPD

How would you treat this patient?

MDT approach: respiratory team, GP, occupational therapists Conservative

  • Smoking cessation and nicotine replacement
  • Pulmonary rehabilitation
  • Immunisations

Medical

  • Bronchodilators and/or inhaled corticosteroids
  • Mucolytics
  • LTOT

Surgical

  • Lung volume reduction
  • Lung transplantation
slide-56
SLIDE 56

56

Respiratory examination: Case 2 – COPD

Indications for LTOT?

LTOT is indicated in non-smokers with:

  • PaO2 <7.3 kPa OR

PaO2 ≥7.3 and <8 kPa AND 1 of the following:

  • Secondary polycythaemia
  • Peripheral oedema
  • Pulmonary hypertension
slide-57
SLIDE 57

57

Top decile question

slide-58
SLIDE 58

58

Recap

‘Retrospective approach’

  • 1. Formulate an OSCE Cases List
  • 2. Prepare your ‘VIVA’ for those cases
  • Positive signs of diagnosis
  • ‘Typical’ findings presentation
  • Risk factors
  • Signs of decompensation
  • List of differentials
  • Complications
  • How would you investigate this patient?
  • How would you manage this patient?
  • 3. Finalise your examination routine
  • Each step of the routine
  • Signs you are looking for
  • Your speech

EXAMINATION ROUTINE PRESENTATION VIVA

  • Perform each step of the

routine confidently

  • Pick up on signs
  • Present findings

systematically

  • List appropriate

differentials based on findings

  • Answer questions

systematically

  • Explain your thinking
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61

61

References

  • 1. Wikicommons. Modified by JHeuser from the modified version by Dake of the original heart diagram

by Wapcaplet. uploaded: 15. April 2006 {{cc-by-sa-2.5,2.0,1.0}} {{WikimediaAllLicensing}}

  • 2. Mrug / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
  • 3. Frank Gaillard / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
  • 4. James Heilman, MD / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
  • 5. U/ttriber. https://i.redd.it/ls1p27ofe4i41.jpg
  • 6. James Heilman, MD / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
  • 7. Desherinka / CC BY-SA (https://creativecommons.org/licenses/by-sa/4.0)
  • 8. Wikicommons. RonEJ. Public domain.
  • 9. National Heart Lung and Blood Institute / Public domain
  • 10. Mcgfowler / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
  • 11. Hellerhoff / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
  • 12. James Heilman, MD / CC BY-SA (https://creativecommons.org/licenses/by-sa/3.0)
slide-62
SLIDE 62

62

Further information

Fill out a feedback form to receive your Certificate of Attendance! Stay up-to-date!

  • Website: www.bitemedicine.com
  • Facebook: www.facebook.com/biteemedicine
  • Instagram: @bitemedicine
  • Email: admin@bitemedicine.com

Presenter’s contact details

  • Instagram: @arun.kiru
  • Youtube: Arun Kiru
  • Twitter: @ArunKirupakaran
  • Email: arunkiru@doctors.org.uk
