Advanced Machine Learning Variational Auto-encoders

Amit Sethi, EE, IITB

Objectives

• Learn how VAEs help in sampling from a data

distribution

• Write the objective function of a VAE
• Derive how VAE objective is adapted for SGD

VAE setup

• We are interested in maximizing the data

likelihood

𝑄 𝑌 = 𝑄 𝑌 𝑨; 𝜄 𝑄 𝑨 𝑒𝑨

• Let 𝑄 𝑌 𝑨; 𝜄 be modeled by 𝑔 𝑨; 𝜄
• Further, let us assume that

𝑄 𝑌 𝑨; 𝜄 = 𝒪 𝑌 𝑔 𝑨; 𝜄 , 𝜏2𝐽

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

We do not care about distribution of z

• Latent variable z is drawn from a standard

normal

• It may represent many different variations of

the data

N θ X z ~ N(0,I)

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Example of a variable transformation

X = g(z) = z/10 + z/‖z‖ z

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Because of Gaussian assumption, the most obvious variation may not be the most likely

• Although the ‘2’ on the right is a better choice

as a variation of the one on the left, the one in the middle is more likely due to the Gaussian assumption

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Sampling z from standard normal is problematic

• It may give samples of z that are unlikely to

have produced X

• Can we sample z itself intelligently?
• Enter Q(z|X) to compute, e.g., Ez~QP(X|z)
• All we need to do is reduce the KL divergence

between P(X) and Ez~QP(X|z)

• Hence, a variational method

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

VAE Objective Setup

D[Q(z) ‖ P(z|X)] = Ez~Q[log Q(z) − log P(z|X)] = Ez~Q[log Q(z) − log P(X|z) − log P(z)] + log P(X) Rearranging some terms: log P(X) − D[Q(z) ‖ P(z|X)] = Ez∼Q[log P(X|z)+ − D[Q(z) ‖ P(z)] Introducing dependency of Q on X: log P(X) − D[Q(z|X) ‖ P(z|X)] = Ez∼Q[log P(X|z)+ − D[Q(z|X) ‖ P(z)]

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Optimizing the RHS

• Q is encoding X into z; P(X|z) is decoding z
• Assume in LHS Q(z|X) is a high capacity NN
• For: Ez∼Q[log P(X|z)+ − D[Q(z|X) ‖ P(z)]
• Assume: Q(z|X) = N(z|μ(X;θ),∑(X;θ))
• Then KL divergence is:

D[N(μ(X),Σ(X)) ‖ N(0,I)] = 1/2 [ tr(Σ(X)) + μ(X)Tμ(X) − k − log det(Σ(X)) ]

• In SGD, the objective becomes maximizing:

EX∼D*log P(X)−D*Q(z|X) ‖ P(z|X)]] =EX∼D[Ez∼Q[log P(X|z)+ − D*Q(z|X) ‖ P(z)]]

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Moving the gradient inside the expectation

• We need to compute the gradient of:

log P(X|z) − D*Q(z|X) ‖ P(z)+

• The first term does not depend on parameters

Q, but Ez∼Q[log P(X|z)] does!

• So, we need to generate z that are plausible,

i.e. decodable

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

The actual model that resists backpropagation

• Cannot backpropagate through a stochastic unit

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

The actual model that resists backpropagation

• EX∼D[Ee∼N(0,I)[log P(X|z=μ(X) +Σ1/2(X)∗e)+−D*Q(z|X)‖P(z)++
• Now, we can BP end-to-end, because expectations are not

with respect to distributions dependent on the model

Reparameterization trick: e∼N(0,I) and z=μ(X)+Σ1/2(X)∗e This works, if Q(z|X) and P(z) are continuous

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Test-time sampling is straightforward

• The encoder pathway, including the

multiplication and addition are discarded

• For getting an estimate of likelihood of a test

sample, generate z, and then compute P(z|X)

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Conditional VAE

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Sample results for a MNIST VAE

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Sample results for a MNIST CVAE

Source: VAEs by Kingma, Welling, et al.; “Tutorial on Variational Autoencoders” by Carl Doersch

Advanced Machine Learning Generative Adversarial Networks

Amit Sethi, EE, IITB

Objectives

• Articulate how using a discriminator helps a

generator

• Write the objective function of GAN
• Write the training algorithm for GAN

GAN trains two networks together

• GAN objective:

min

𝐻 max 𝐸

𝑊 𝐸, 𝐻 = 𝔽𝒚~𝑞𝒚(𝒚) log 𝐸 𝒚 + 𝔽𝒜~𝑞𝒜 𝒜 [log(1 − 𝐸(𝐻 𝒜 )] z G x' x D y

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

At the solution, the transformed distribution from z will emulate px(x)

• As training progresses, the distributions of the

transformed noise and the data will become indistinguishable

G G G G D D D D px(x) px(x) px(x) px(x) Training steps 

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

The trick is to allow D to catch up before improving G in each iteration

• For training iterations
• For k steps
• Update discriminator by ascending
• 𝛼𝜄𝐸

1 𝑛

log 𝐸 𝒚 𝑗 + log(1 − 𝐸 𝐻(𝒜 𝑗 )

𝑛 𝑗=1

• Update generator by descending
• 𝛼𝜄𝐻

1 𝑛

log(1 − 𝐸 𝐻(𝒜 𝑗 )

𝑛 𝑗=1

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

An optimum exists

• For a fixed generator, 𝐸 𝒚 =

𝑞𝒚(𝒚) 𝑞𝒚 𝒚 +𝑞𝐻(𝒚)

• Because

𝔽𝒚~𝑞𝒚(𝒚) log 𝐸 𝒚 + 𝔽𝒜~𝑞𝒜 𝒜 [log(1 − 𝐸(𝐻 𝒜 )] = 𝑞𝒚 𝒚 log 𝐸 𝒚 + 𝑞𝐻 𝒚 log 1 − 𝐸 𝒚 𝑒𝑦

𝒚

And, optimal of 𝑏 log 𝑧 + 𝑐 log(1 − 𝑧) is 𝑏

𝑏+𝑐

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

Generator’s optimization reduces as follows…

• 𝔽𝒚~𝑞𝒚(𝒚) log 𝐸 𝒚

+ 𝔽𝒜~𝑞𝒜 𝒜 [log(1 − 𝐸(𝐻 𝒜 )] = 𝔽𝒚~𝑞𝒚(𝒚) log 𝑞𝒚(𝒚) 𝑞𝒚 𝒚 + 𝑞𝐻(𝒚) + 𝔽𝒚~𝑞𝑯 𝒚 log 𝑞𝑯(𝒚) 𝑞𝒚 𝒚 + 𝑞𝐻(𝒚) = − log 4 + 𝐿𝑀 𝑞𝒚(𝒚) 𝑞𝒚 𝒚 + 𝑞𝐻(𝒚) 2 + 𝐿𝑀 𝑞𝐻(𝒚) 𝑞𝒚 𝒚 + 𝑞𝐻(𝒚) 2

• This assumes that the generator and the discriminator are

high capacity such that these can model the desired distributions arbitrarily well.

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

Some sample generations and interpolations of latent vector

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

DC-GAN was designed to generate better images

• No pooling – convolutions with > or < 1 stride
• No fully connected layers
• Heavy use of batchnorm
• Use ReLU in G, leakyReLU in D in all but final layers
• Use tanh in the last layer of G

Source: “Unsupervised Representation Learning with Deep Convolutional Generative Adversarial Networks” by Radford et al. in ICLR 2016

While mode-collapse isn’t evident, there is some underfitting

Source: “Unsupervised Representation Learning with Deep Convolutional Generative Adversarial Networks” by Radford et al. in ICLR 2016

GAN features can directly be used for classification

Source: “Unsupervised Representation Learning with Deep Convolutional Generative Adversarial Networks” by Radford et al. in ICLR 2016

GANs allow latent vector “arithmetic”

Source: “Unsupervised Representation Learning with Deep Convolutional Generative Adversarial Networks” by Radford et al. in ICLR 2016

Advantages and disadvantages of GAN

• Markov chains not

needed

• Only backprop used
• No inference needed
• Models a wide range of

functions

• No explicit generator
• Need to sync D with G
• Mode collapse

Source: “Generative Adversarial Nets” by Goodfellow et al. in NeurIPS 2014

Conditional GAN introduces another variable (e.g. class)

• Instead of the GAN objective:

𝔽𝒚~𝑞𝒚(𝒚) log 𝐸 𝒚 + 𝔽𝒜~𝑞𝒜 𝒜 [log(1 − 𝐸(𝐻 𝒜 )]

• CGAN uses a modified objective:

𝔽𝒚~𝑞𝒚(𝒚) log 𝐸 𝒚|𝒛 + 𝔽𝒜~𝑞𝒜 𝒜 [log(1 − 𝐸(𝐻 𝒜|𝒛 )]

Source: “Conditional Generative Adversarial Nets” by Mirza and Osindero, Arxiv 2014

Conditional GAN introduces another variable (e.g. class)

Source: “Conditional Generative Adversarial Nets” by Mirza and Osindero, Arxiv 2014

Each row is conditioned upon one digit label of a CGAN

Source: “Conditional Generative Adversarial Nets” by Mirza and Osindero, Arxiv 2014

Interpretable latent variables – InfoGAN

• GAN objective:

min

𝐻 max 𝐸

𝑊 𝐸, 𝐻 = 𝔽𝒚~data log 𝐸 𝒚 + 𝔽𝒜~noise[log(1 − 𝐸(𝐻 𝒜 )]

• Introduce extra (supposedly interpretable)

latent variables 𝑑 in addition to 𝑨

• InfoGAN objective:

min

𝐻 max 𝐸

𝑊

𝐽 𝐸, 𝐻 = 𝑊 𝐸, 𝐻 − 𝜇 𝐽 𝑑, 𝐻 𝑨, 𝑑

• Mutual information:

𝐽 𝑑, 𝐻 𝑨, 𝑑 = 𝐼 𝑑 − 𝐼 𝑑 𝐻 𝑨, 𝑑

Source: “InfoGAN: Interpretable Representation Learning byInformation Maximizing Generative Adversarial Nets” by Chen et al., in NeurIPS 2016.

Variational information maximization to the rescue

• Mutual information:

𝐽 𝑑, 𝐻 𝑨, 𝑑 = 𝐼 𝑑 − 𝐼 𝑑 𝐻 𝑨, 𝑑 = 𝔽𝑦~𝐻(𝑨,𝑑) 𝔽𝑑′~𝑄(𝑑|𝑦) log 𝑄(𝑑′|𝑦) + 𝐼 𝑑 = 𝔽𝑦~𝐻(𝑨,𝑑) 𝐿𝑀 𝑄 . 𝑦 𝑅 . 𝑦 + 𝔽𝑑′~𝑄(𝑑|𝑦) log 𝑅(𝑑′|𝑦) + 𝐼 𝑑 ≥ 𝔽𝑦~𝐻(𝑨,𝑑) 𝔽𝑑′~𝑄(𝑑|𝑦) log 𝑅(𝑑′|𝑦) + 𝐼 𝑑

• Further: 𝔽𝑦~𝑌,𝑧~𝑍|𝑦 𝑔 𝑦, 𝑧

= 𝔽𝑦~𝑌,𝑧~𝑍|𝑦,𝑦′~𝑌|𝑧 𝑔 𝑦′, 𝑧 under certain conditions, implies that previous quantity is 𝑀𝐽 𝐻, 𝑅 = 𝔽𝑑~𝑄 𝑑 ,𝑦~𝐻(𝑨,𝑑) log 𝑅(𝑑|𝑦) + 𝐼 𝑑

• Overall: min

𝐻,𝑅 max 𝐸

𝑊

𝐽 𝐸, 𝐻, 𝑅 = 𝑊 𝐸, 𝐻 − 𝜇 𝑀𝐽 𝐻, 𝑅

Source: “InfoGAN: Interpretable Representation Learning byInformation Maximizing Generative Adversarial Nets” by Chen et al., in NeurIPS 2016.

InfoGAN visually

Inspiration source: “InfoGAN — Generative Adversarial Networks Part III” Zak Jost, TowardsDataScience.com

z G x' x D y c Q c'

• The figure elements in red were added to

InfoGAN on top of a regular GAN

• C can be a mix of class code and disentangled

continuous variables

Results are more interpretable

Source: “InfoGAN: Interpretable Representation Learning byInformation Maximizing Generative Adversarial Nets” by Chen et al., in NeurIPS 2016.

Results are more interpretable

Source: “InfoGAN: Interpretable Representation Learning byInformation Maximizing Generative Adversarial Nets” by Chen et al., in NeurIPS 2016.
