ACCORD: Associativity for DRAM Caches by Coordinating Way-Install and Way-Prediction

ISCA 2018

1

Vinson Young (GT) Chiachen Chou (GT) Aamer Jaleel (NVIDIA) Moinuddin K. Qureshi (GT)

Authors:

4-8x Bandwidth (of traditional memory)

3D-DRAM MITIGATES BANDWIDTH WALL

2

Hybrid Memory Cube (HMC) from Micron, High Bandwidth Memory (HBM) from Samsung 3D-Stacked DRAM

✔

Limited Capacity

✘

Memory

3D-DRAM + High-Capacity Memory = Hybrid Memory

Modern system packing many cores è Bandwidth Wall

OS-visible Space

System Memory (NVM / DRAM)

USE 3D-DRAM AS A CACHE

3

DRAM-Cache (3D-DRAM)

Memory Hierarchy

fast slow CPU L1$ L2$ L3$ CPU L2$ L1$

Using 3D-DRAM as a DRAM cache, can improve memory bandwidth (and avoid OS/software change)

MCDRAM from Intel

Organize at line granularity (64B) for capacity/BW utilization Gigascale cache needs large tag-store (tens of MBs) 3D-DRAM

ARCHITECTING LARGE DRAM CACHES

4

4GB Data 128 MB Tags Tags? Too large for SRAM

Organize at line granularity (64B) for high cache utilization Gigascale cache needs large tag-store (tens of MBs) Practical designs must store Tags in DRAM 3D-DRAM

ARCHITECTING LARGE DRAM CACHES

5

How to architect tag-store for low-latency tag access? 4GB Data 128 MB Tags

EFFICIENT TAG ORGANIZATION (KNL CACHE)

6

Practical designs are 64B line-size, store Tag-With-Data, and are direct-mapped, to optimize for hit-latency.

Tag Data Tag Data Tag Data Tag Data

Tag-With-Data [Alloy Cache, Intel Knights Landing]

Single Tag+Data Lookup (1x hit latency), but direct-mapped

Intel Knights Landing Product (MCDRAM) uses this DRAM-cache organization.

60 70 80 90 1

• w

a y 2

• w

a y 4

• w

a y 8

• w

a y Hit Rate (%)

Reduce 25%

• f misses

POTENTIAL OF ASSOCIATIVITY

7

How can we make DRAM caches associative?

Assumes 16-core system, with 4GB DRAM-Cache, in front of PCM memory.

ASSOCIATIVITY OPTION 1: SERIAL TAG LOOKUP Serial Tag Lookup enables associativity, but, it has serialization delay.

8

A B

Way 0 Way 1 Address

A B

If miss

ASSOCIATIVITY OPTION 2: PARALLEL TAG LOOKUP

Parallel Lookup avoids serialization latency, but, it introduces 2x bandwidth cost.

9

A B

Way 0 Way 1 Address

A B

60 70 80 90 1-way 2-way 4-way 8-way Hit Rate (%)

0.5 1 1.5

2-way 4-way 8-way

(b) Speedup (Parallel)

Speedup (Parallel)

Reduce 25%

• f misses
• 46%

ASSOCIATIVITY FOR DRAM CACHE (PARALLEL)

10

Increasing associativity naively actually degrades performance due to increased BW cost

60 70 80 90 1

• w

a y 2

• w

a y 4

• w

a y 8

• w

a y Hit Rate (%)

0.5 1 1.5

2

• w

a y 4

• w

a y 8

• w

a y

(b) Speedup (Parallel)

Speedup (Parallel) 0.5 1 1.5 2

• w

a y 4

• w

a y 8

• w

a y

(c) Speedup (Idealized)

Speedup (Idealized)

Reduce 25%

• f misses
• 46%

21%

ASSOCIATIVITY FOR DRAM CACHE (IDEAL)

11

With latency / BW

• f direct-mapped

Associativity must still maintain the latency/BW

• f direct-mapped caches. How?

OPTION 3: WAY-PREDICTED TAG LOOKUP Way-Predicted Tag Lookup can obtain improved hit- rate, with BW / latency of direct-mapped cache.

12

Way-Predicted Tag Lookup

A B

Way 0 Way 1 Address

B

If miss Way Prediction

Accuracy (4-way) 74.3% 91.6% Accuracy (8-way) 63.2% 81.2% MRU Pred (1bit/set) Partial-Tag (4bit/line) SRAM Storage 4MB 32MB Way-Pred Accuracy (2-way) 85.7% 97.3%

WAY-PREDICTION ACCURACY & COST Prior methods for way-prediction have low accuracy and/or have high storage overhead.

13

TOWARDS ASSOCIATIVITY W/ WAY-PREDICTION

14

Way-Predicted Tag Lookup

A B

Way 0 Way 1 Address

B

If miss Way Prediction

Goal: Low storage-overhead and high accuracy way-prediction, to enable associative DRAM cache

ACCORD OVERVIEW

• Background
• ACCORD

– Probabilistic Way-Steering (PWS) – Ganged Way-Steering (GWS) – Skewed Way-Steering (SWS)

• Summary

15

INSIGHT: WAY-PREDICTABILITY AT LOW STORAGE?

Insight: Modifying install policy can make way- prediction much simpler!

16

EVEN ODD Way 0 Way 1 EVEN ODD ODD EVEN

Base Install Policy (Rand)

EVEN ODD EVEN ODD ODD EVEN

Tag-based Install Policy

Way 0 Way 1 Hard-to-predict (~50%) Predict 100%! But, direct-mapped

PROPOSAL: ACCORD AssoCiativity by CoORDinating way-install and prediction. ACCORD achieves a way-predictable cache at low cost.

17

Way 0 Way 1 A2 B3 A3 B5 B7 Way Install Policy Way Predictor Coordinate

ACCORD OVERVIEW

• Background
• ACCORD

– Probabilistic Way-Steering (PWS) – Ganged Way-Steering (GWS) – Skewed Way-Steering (SWS)

• Summary

18

PROBABILISTIC WAY-STEERING PWS enables way-predictability, by trading speed of learning to use both ways (hit-rate)

19

Install using PWS Page A,B Bias=90% 10% Static prediction: ~90% B1 B2 B3 B4 B6 B7 B0 B5 Way 0 Way 1 Address A1 A2 A3 A4 A6 A7 A0 A5 B1 B2 B3 B4 B6 B7 B0 B5 A1 A2 A3 A4 A6 A7 A0 A5 Preferred Will use both ways, improve hit-rate

SENSITIVITY TO PWS PROBABILITY

20

0% 20% 40% 60% 80% 100% 0% 2% 4% 6% 8% 10% 12% 14% 50% 60% 70% 80% 85% 90% 100% Way-Pred Accuracy (%) Miss Reduction (%) Bias for selecting “preferred way” Way-Pred Accuracy

2-way design Direct-mapped Preferred-way Install Probability = x% bias to install in preferred way

SENSITIVITY TO PWS PROBABILITY

21

0% 20% 40% 60% 80% 100% 0% 2% 4% 6% 8% 10% 12% 14% 50% 60% 70% 80% 85% 90% 100% Way-Pred Accuracy (%) Miss Reduction (%) Preferred-way Install Probability Miss Reduction (%) Way-Pred Accuracy

2-way design Direct-mapped

SENSITIVITY TO PWS PROBABILITY

22

2.6% 3.7% 4.7% 5.5% 5.6% 5.3% 0.0%

0% 20% 40% 60% 80% 100% 0% 2% 4% 6% 8% 10% 12% 14% 50% 60% 70% 80% 85% 90% 100% Way-Pred Accuracy (%) Miss Reduction (%) Speedup (%) Preferred-way Install Probability Speedup Miss Reduction (%) Way-Pred Accuracy

Preferred-way Install Probability (85%) provides best trade-off of hit-rate for WP accuracy, for 5.6% speedup.

5.6% speedup

ACCORD OVERVIEW

• Background
• ACCORD

– Probabilistic Way-Steering (PWS) – Ganged Way-Steering (GWS) – Skewed Way-Steering (SWS)

• Summary

23

GANGED WAY-STEERING

24

B1 B2 B3 B4 B6 B7 B0 B5 Way 0 Way 1 Address B0 B1 B2 B3 B4 B6 B7 B5 Way 0 Way 1 Address B0 B1 B2 B3 B4 B6 B7 B5 A0 A1 A2 A3 A4 A6 A7 A5 A1 A2 A3 A4 A6 A7 A0 A5 B1 B2 B3 B4 B6 B7 B0 B5 A1 A2 A3 A4 A6 A7 A0 A5 Probabilistic Way-Steering Per-line randomized decision Ganged Way-Steering Per-page rand decision Preferred Preferred Pred ~50% Pred >90% Ganged Way-Steering makes install decision at large granularity, to improve predictability for workloads with high spatial locality.

GANGED WAY-STEERING IMPLEMENTATION

25

Way 0 Way 1 A2 B3 A3 B5 B7

0x001

RegionID Way Guide Install Recent Install Table (RIT) Install RegionID

0x101

Way Predict Way Recent Lookup Table (RLT) Access

GWS Per-Region Last-Way install + Last-Way prediction. 64-entry RIT and 64-entry RLT needs only 320 Bytes.

1

PWS+GWS WAY-PREDICTION ACCURACY

26

70% 75% 80% 85% 90% 95% 100%

PWS+GWS PWS Libquantum

GWS enables spatial workloads to have near-100% accuracy PWS has ~85% base accuracy

Combination of PWS+GWS achieves 90% accuracy, at the cost of 320B storage.

Way-Pred Acc (%)

70% 75% 80% 85% 90% 95% 100%

Average (21 workloads) PWS+GWS PWS

PWS+GWS (ACCORD 2-WAY) RESULTS PWS + GWS gets 7.3% of 10% speedup of perfectly-predicted 2-way cache.

7.3% speedup

27

System assumes 4GB DRAM Cache, and PCM-based main memory.

0% 2% 4% 6% 8% 10% 12%

Speedup PWS PWS+GWS Perfect

ACCORD OVERVIEW

• Background
• ACCORD

– Probabilistic Way-Steering (PWS) – Ganged Way-Steering (GWS) – Skewed Way-Steering (SWS)

• Summary

28

DIFFICULTY IN SCALING TO N-WAYS

• Scaling ACCORD to N-ways

– ACCORD 4-way has 3% speedup – ACCORD 8-way has 6% slowdown…

We need solutions to reduce miss-confirmation

• Miss confirmation: N-way cache needs N accesses

to confirm line is not resident

29

E A C B D Way 0 Way 1 Way 2 Way 3 Address E Miss!

SOLUTION: SKEWED WAY-STEERING Restricting placement, reduces miss-confirmation è hit-rate benefits without any storage overhead

30

Only 2 lookups to determine miss Way 0 Way 2Way 3 E Access: A B C A B 4-way with 2-skew: Access: ABC One Preferred + One Alternate way Way 1

SPEEDUP FROM ACCORD (WITH SWS)

31

0% 2% 4% 6% 8% 10% 12%

Speedup 2-Way

SWS 8-way achieves 11% speedup

4-Way 8-Way

ACCORD OVERVIEW

• Background
• ACCORD

– Probabilistic Way-Steering (PWS) – Ganged Way-Steering (GWS) – Skewed Way-Steering (SWS)

• Summary

32

SUMMARY OF ACCORD

§ ACCORD: associative DRAM caches by coordinating way-

install and way-prediction.

§ Probabilistic Way-Steering

§ Biased-install enables accurate static way-prediction

§ Ganged Way-Steering

§ Region-based install enables accurate region-based way-prediction

§ Skewed Way-Steering

§ Skew enables flexibility in line placement, while maintaining miss cost

§ ACCORD enables associativity at negligible storage cost

(320B), to achieve 11% speedup.

33

ACCORD BACKUP SLIDES

ACCORD backup slides

34

REPLACEMENT POLICY?

• LRU

– State in SRAM

• 1-bit per line needs 8MB. Size of Last-level cache

– State in DRAM

• 9% slowdown due to state-update cost (Hit to alternate way)

35

COMPARISON TO OTHER WAY PREDICTORS

36

• 6%
• 4%
• 2%

0% 2% 4% 6% 8% 10% 12%

Speedup

ACCORD outperforms other predictors while needing negligible storage overhead (320 B)

COLUMN-ASSOCIATIVE CACHE

• Column-associative / Hash-Rehash cache

– Install lines in preferred way (way-0) – On eviction, move line to alternate way (way-1) – On hit to alternate way, move to preferred way

• Effectiveness

– In general, way-prediction accuracy similar to MRU – But, requires significant bandwidth to swap lines on hit to alternate way. CA-cache thus causes 4% slowdown.
