A Recommendation System for Software Function Discovery Naoki Ohsugi Software Engineering Laboratory, Graduate School of Information Science, Nara Institute of Science and Technology Tuesday 16 December, 2003. International Workshop on


slide-1
SLIDE 1

A Recommendation System for Software Function Discovery

Naoki Ohsugi Software Engineering Laboratory, Graduate School of Information Science, Nara Institute of Science and Technology

Tuesday 16 December, 2003. International Workshop on Community-Driven Evolution of Knowledge Artifacts

slide-2
SLIDE 2

2 of 14

Growth of Software Functions

Application software is getting more complicated and providing more functions.

Total number of menu items (Microsoft Office)

Word 2000: 660 Word 2002: 772 Excel 2000: 705 Excel 2002: 792 PowerPoint 2000: 565 PowerPoint 2002: 646

Screenshot of MS-Word 2002

Users can’t find useful functions from too many functions.

slide-3
SLIDE 3

3 of 14

Users Could Not Find Some Useful Functions!

Subjects: 32 users in our lab. Period: 22 months Total Number of Different Functions Maximum Number of Functions Used Minimum Number of Functions Used Average Number of Functions Used

Excel2000 Excel2002 PPT2000 PPT2002 Word2000 Word2002 Number of Functions

705 792 565 646 660 772 75 83 189 147 143 120 10 12 18 31 22 11 38 26 80 67 66 32 100 200 300 400 500 600 700 800 900

10.6% 10.5% 33.5% 22.8% 21.7% 15.5% 1.4% 1.5% 3.2% 4.8% 3.3% 1.4% 5.4% 3.3% 14.2% 10.4% 10.0% 4.1%

slide-4
SLIDE 4

4 of 14

A Recommendation System for Software Function Discovery

The system recommends individual users a set of candidate functions, which may be useful. Our solution is a Collaborative Filtering approach.

Here’s my recommendation:

Tools Word Count… 21 pts Insert Date Time… 20 pts Tools Thesaurus… 18 pts Insert Footnote… 18 pts Tools Spelling… 17 pts

slide-5
SLIDE 5

5 of 14

What is Collaborative Filtering (CF)?

“Collaborative” means using some users’ knowledge for filtering. “Filtering” means selecting useful items from large amount of items.

Using some users’ knowledge F K A B D E C G I J H L N O M P Q S T R Large amount of items F is good! K is cool!

? ?

Selecting useful items F F K K

slide-6
SLIDE 6

6 of 14

Voting-based Recommendation Systems with CF

The systems collect explicit votes as users’ knowledge.

Amazon.com (Book recommendation system)

http://www.amazon.com

MovieLens (Movie recommendation system)

http://www.movielens.umn.edu

slide-7
SLIDE 7

7 of 14

Logging Usage as Users’ Knowledge

The proposed system automatically collects the records of executed functions (Usage logs) as users' knowledge. Usage logs are collected from some users via the Internet.

Server of the System The Internet

User

Application Software e.g. MS-Word, Excel Usage log as shown below: 2002/02/03 18:50:41 Formatting->Font… 2002/02/03 18:50:45 File->Save As… Log Collector VBA Plug-In

slide-8
SLIDE 8

8 of 14

Function A Function B Function C Function D Function A Function B Function C Function D

Dissimilar users Similar users

Step1: Computing Similarities

Computing similarities between the target user and the

  • ther users

Function H Function I Function J Function K Function E Function F Function G

Target user User 1 User 2 User 3 User 4

Function A Function B Function C Function A Function A Function C Function A Function B Function C Function D Function A Function B Function C Function D Function A Function A Function C

slide-9
SLIDE 9

9 of 14

Dissimilar users Similar users

Step 2: Delivering Knowledge

Delivering the useful functions candidate, which were frequently used by the similar users'.

Function A Function B Function C Function D Function A Function B Function C Function D Function H Function I Function J Function K Function A Function B Function C Function E Function F Function G

Target user

Function A Function B Function C Function D Function A Function B Function C Function D Function A Function B Function C Function D

User 1 User 2 User 3 User 4

Function B Function D

slide-10
SLIDE 10

10 of 14

1 2 3 4 5 6 7 User 3 Undo Save Clear Cut Copy Paste Redo 60% 20% 6% 5% 4% 3% 2% 1 2 3 4 5 6 7 User 2 Save Undo Redo Copy Paste Cut Clear 55% 25% 10% 4% 3% 2% 1% Correlation based similarity +0.41 +0.97 (Range of value [-1.00, +1.00])

Calculating Similarities by Correlation Coefficient

The dominant frequencies (e.g., “Undo” or “Save”) over-affect similarity

computations.

Conventional Similarity Calculation

1 2 3 4 5 6 7 Target user Undo Save Redo Copy Paste Cut Clear 60% 20% 10% 4% 3% 2% 1%

slide-11
SLIDE 11

11 of 14

Rank correlation based similarity +0.90 +0.05

Better Similarity Calculation

Calculating Similarities by Rank Correlation

The dominant frequencies ("Undo" & "Save") do not affect similarity

computations. Correlation based similarity +0.41 +0.97 1 2 3 4 5 6 7 User 3 Undo Save Clear Cut Copy Paste Redo 60% 20% 6% 5% 4% 3% 2% 1 2 3 4 5 6 7 User 2 Save Undo Redo Copy Paste Cut Clear 55% 25% 10% 4% 3% 2% 1% 1 2 3 4 5 6 7 Target user Undo Save Redo Copy Paste Cut Clear 60% 20% 10% 4% 3% 2% 1%

slide-12
SLIDE 12

12 of 14

Ndpm [0.0, 1.0] 0.0 is the best 1.0 is the worst Comparison

Evaluating Accuracy of Recommendation

Yao’s ndpm measure

  • * Y.Y. Yao, “Measuring Retrieval Effectiveness Based on User Preference of Documents”,
  • J. of American Society for Information Science, 46, 2, 1995, pp.133-145.

User’s Ideal Recommendation Interview for user

  • 1. Function A
  • 2. Function B
  • 3. Function C
  • 4. Function D

System System’s Recommendation

  • 1. Function A
  • 2. Function B
  • 3. Function C
  • 4. Function D

Usage logs 6 users 22 months

slide-13
SLIDE 13

13 of 14

Experimental Result

0.514 0.404 0.396 0.383 0.355 0.2 0.3 0.4 0.5 0.6

Ndpm Each user’s ndpm Average of ndpm 0.5 of ndpm

User Count Random Base Case Correlation based Similarity Rank Correlation based Similarity

Algorithms Collected usage logs of Ms-Word 2000 Subjects: 6 users in our lab. Period: 22 months

slide-14
SLIDE 14

14 of 14

Conclusion

I proposed a recommendation system to help users discover useful functions. I evaluated the accuracy of recommendation.

The result suggested the proposed system has a potential

to provide useful recommendation for software function discovery.
