A Framework for Conceptualizing Social Engineering Attacks Jose J. Gonzalez Agder University College, Grimstad, Norway Jose M. Sarriegi, Alazne Gurrutxaga Tecnun (University of Navarra) San Sebastian, Spain CRITIS06, Samos Introduction


slide-1
SLIDE 1

CRITIS’06, Samos

A Framework for Conceptualizing Social Engineering Attacks

Jose J. Gonzalez

Agder University College, Grimstad, Norway

Jose M. Sarriegi, Alazne Gurrutxaga

Tecnun (University of Navarra) San Sebastian, Spain

slide-2
SLIDE 2

CRITIS’06, Samos

Introduction

  • Social engineering consists of acquiring information

about computer systems through non-technical means

  • While technical security of most critical

infrastructure is high…

  • …it remains vulnerable to attacks from social

engineers, whether outsiders or insiders

  • Recent studies conclude that it is relatively cheap

and easy to mount a large scale social engineering attack with a high success rate

slide-3
SLIDE 3

CRITIS’06, Samos

Objective of the paper

  • Objective: Classify social engineering attacks

according to their dynamic behaviour using system archetypes

  • This classification would help designing effective

multilayered security procedures

slide-4
SLIDE 4

CRITIS’06, Samos

A feedback view of social engineering

  • Social engineers often use several small attacks

to put them in the position to reach their final goal

  • The attack is a dynamic process where the
  • utcome of an action is fed back to execute the

next action

  • Organizational defences activate security

controls that could by anticipated by the attacker.

slide-5
SLIDE 5

CRITIS’06, Samos

Behaviour of a “Problem”

100 200 300 400 500 600 1980 1985 1990 1995 2000 2005 Tourists

slide-6
SLIDE 6

CRITIS’06, Samos

Causal Loop Diagram

Tourists visiting Samos island Income from tourism Advertisements in international medias + + + R1 Tourist density Tourists' satisfaction +

  • +

B2 Investment in tourism infrastructures + + R3

slide-7
SLIDE 7

CRITIS’06, Samos

Generic System Archetypes

action

  • utcome
  • rganizational reaction

IC UC SOL boundary delay delay action

  • utcome
  • rganizational reaction

IC UC SOL boundary delay delay

slide-8
SLIDE 8

CRITIS’06, Samos

The four system archetypes

Out of control Reinforcing Balancing Relative Achievement Reinforcing Reinforcing Underachievement Balancing Reinforcing Relative Control Balancing Balancing Archetype Unintended consequence loop Intended consequence loop

slide-9
SLIDE 9

CRITIS’06, Samos

Hypothesis

  • Descriptions of social engineering attacks in

terms of system archetypes have qualities as strategic patterns. They:

– Conceptualize crucial aspects of the attack and defense process – Are cognitively simple – Are fairly easy to recognize and to interpret – Are modular and can be combined

slide-10
SLIDE 10

CRITIS’06, Samos

External social engineer targeting an explicit goal

  • An external agent who is trying to achieve a

particular goal

  • As he comes closer to the desired outcome, the

level of protection is higher and higher

  • Hence, the social engineer uses elements from

the outcome to gain fake authority

slide-11
SLIDE 11

CRITIS’06, Samos

External social engineer targeting an explicit goal

desired outcome action

  • utcome

+ +

  • IC (B)

protection level

+

  • UC (B)

agent's authorization level

+

  • SOL (B)

boundary 'delay' ' delay '

slide-12
SLIDE 12

CRITIS’06, Samos

Social engineer targeting a long- term parasitic relationship

  • A patient malicious insider provides an external

party long term access to more and more valuable assets

  • The organization enacts separation of duties
  • The social engineer needs to become a star

performer to bypass security controls

slide-13
SLIDE 13

CRITIS’06, Samos

Social engineer targeting a long- term parasitic relationship

action

  • utcome

+ +

IC (R)

  • utcome accessibility
  • +

UC (B) agent

  • rganizational

performance

+ +

SOL (R) boundary 'delay' ' delay '

slide-14
SLIDE 14

CRITIS’06, Samos

Disgruntled insider as social engineer

  • An insider acts against his firm, obtaining

escalating “outcomes”. As he is successful his motivation to proceed increases

  • If precursors are detected the social engineer

can be warned or even fired

  • He should manage to self-control, targeting

major outcomes in a covert way

slide-15
SLIDE 15

CRITIS’06, Samos

Disgruntled insider as social engineer

action

  • utcome

malicious motivation + + + IC (R) precursors warnings + + + UC (R) regulatory action +

  • SOL (B)

boundary 'delay' ' delay '

slide-16
SLIDE 16

CRITIS’06, Samos

A social engineer targeting an ambitious goal

  • An insider who is determined to launch a

massive strike

  • But he also actives security controls that could

compromise his desired outcome

  • The social engineer should use the obtained
  • utcome not only for generating more actions,

but also to weaken security controls

slide-17
SLIDE 17

CRITIS’06, Samos

A social engineer targeting an ambitious goal

action

  • utcome

security controls

+

  • IC (B)

UC (R)

+

desired outcome +

  • SOL (R)

boundary 'delay' ' delay '

slide-18
SLIDE 18

CRITIS’06, Samos

Conclusions

  • System archetypes represent at a high level of

abstraction and aggregation the main modes of social engineering attacks

  • Although they do not do full justice to real cases

are a way to conceptualize the most salient aspects

  • f the attack and defence for some time interval
  • They are helpful to design security controls that

provide multilayered feedback against the social engineer’s primary intended consequence and solution loops

slide-19
SLIDE 19

CRITIS’06, Samos

A Framework for Conceptualizing Social Engineering Attacks

Jose J. Gonzalez

Agder University College, Grimstad, Norway

Jose M. Sarriegi, Alazne Gurrutxaga

Tecnun (University of Navarra) San Sebastian, Spain
