AFFERENT BASIS OF VISUAL RESPONSE PROPERTIES IN AREA MT OF THE MACAQUE. I. EFFECTS

OF STRIATE CORTEX REMOVAL

Review of Rodman, H. R., Gross, C. G., and Albright,

• T. D. (1989)

Louis Janse van Rensburg & Terence Tong

MIDDLE TEMPORAL AREA (MT)

¢ Posterior Bank of the Superior Temporal Sulcus

Taken from http://thebrain.mcgill.ca/flash/a/a_02/a_02_cr/a_02_cr_vis/a_02_cr_vis.html

BACKGROUND

¢ MT neurons selective for both direction and

speed of stimulus motion

¢ Cells with similar preferred direction are in

columns

¢ Lesion studies show disruption of thresholds for

detection and discrimination of visual motion

¢ Connections — Striate Cortex — V2, V3 — MST, FST and VIP — V4, and possibly V3A and PO — Inferior and Lateral Pulvinar — Claustrum, pons and superior colliculus

DEPENDENCE OF MT

¢ Striate Cortex — Major part of ascending input comes from Striate

cortex, V2, V3

— Loss of visual responsiveness following removal of

striate input

— Antidromic experiments ¢ Other Regions — Superior Colliculus — Tectopulvinar-MT path — Superior temporal polysensory area

EFFECTS OF STRIATE CORTEX LESIONS

METHODS & MATERIALS

¢ Subjects and Striate Cortex lesions: — 3 Male Macaca fascicularis (no. 542, 555, 561)

¢ Partial unilateral striate cortex ablation (542) ¢ Partial bilateral striate cortex ablation (555) ¢ Total bilateral striate cortex ablation (561) ¢ 5-6 week recovery ¢ Animals were restrained and anesthetized during all

surgeries (Atropine, Ketamine, Nitrous oxide + Fluothane, Pavulon and Valium)

METHODS & MATERIALS

¢ Preparation for recording — Prior to Striate Cortex Lesion Surgeries:

¢ Stereotaxically positioned 5cm diameter stainless steel

recording chamber implanted and fixated with screws and dental acrylic over midline.

¢ 1 week before lesion surgeries

— Prior to recording

¢ Pupils dilated (Cyclogyl) ¢ Corneas covered with contact lenses to ensure image

fixation on tangent screen at 57 cm.

METHODS & MATERIALS

¢ Recording Procedure and Visual Stimulation — MT Single/Multiunit recordings using T.

microelectrodes

— Single/multiunit sites tested for:

¢ Visual responsiveness ¢ Direction selectivity ¢ This refers to relative strength of responses to preferred

• vs. anti-preferred directions

¢ 0 = no direction preference, 5 = strong preference ¢ Broadness of direction tuning/sharpness/strength of

direction selectivity

¢ i.e. how selective that single/multiunit site is for angular

directions ranging further away from optimal direction

¢ 0 = no selectivity, 5 = strong selectivity. ¢ Binocularity of unit sites ¢ Unit Responses compared for ipsi/contralateral eye input.

METHODS & MATERIALS

¢ cont. — RF’s corresponding to MT unit sites mapped:

¢ Using smallest stimulus capable of evoking cell responses ¢ Determined borders by assessing where in the visual field

responses stopped.

— Computer-controlled stimulus display varying stimulus:

¢ Size (0.5-1 degree width x 3-20 degree length) ¢ Speed (2 -64 degrees/second) ¢ Angular Direction 8 or 16 different directions of bar/slit

stimuli movement (always perpendicular to length of the bar)

¢ “optimal with hand-testing” (Blind-sight implication

discussed)

— Histology: perfusion, staining & 50 nanometer slices — Also assessed LGN degradation corresponding to Striate

Lesioning and calculated:

¢ 1 degree error in estimated visual field representation at 10

degree eccentricities, and (for no. 542 only) 5-10 degree error at 40 degree eccentricity. (IMPORTANT: Comparison RF within/

• utside destroyed visual field).

RESULTS

¢ Based on 269 MT sites (165 single, 104 multi) — Histologically determined to be within

myeloarchitectonic borders of MT

— 3 categories of MT unit RF correspondence to Visual

Field defect

¢ RF almost entirely within Visual field defect (RF area =

%80-%100 within defect)

¢ RF partially within (%20-80%) ¢ RF outside

RESULTS

¢ Histological Verification of Topographic/Visual

Map Defect

— Assessed Retrograde Degeneration of LGN and

corresponding Striate Cortex Ablation (accuracy/ control measure)

— Case no. 542 Unilateral lesion

¢ Left Striate cortex lesion: right hemi-field defect ¢ 10 degrees above midline at foveal region ¢ 20 degrees above and below horizontal meridian ¢ 45 degrees most peripheral (northeast/top right in visual

field)

• NO. 542

Case no. 542 Unilateral lesion

• Left Striate cortex lesion:

right hemi-field defect

• 10 degrees above midline at

foveal region

• 20 degrees above and below

horizontal meridian

• 45 degrees most peripheral

(northeast/top right in visual field)

RESULTS

¢ Case no. 555 (partial

Bilateral lesion)

— Symmetrical — Dorso-medial edge along

lunate sulcus spared

— Slight invasion of

posterior portion of Calcarine Sulcus

— Limited damage to V2 — Circular defect: 4

degrees extension upper field, 6 degrees into the lower field and 7 degrees along horizontal meridian.

RESULTS

¢ Case no. 561 —

Total lesioning of Striate except for small “tag” of anterior-most calcarine sulcus.

—

Extended past Lunate Sulcus into V2 (dorsally)

—

Ventral Extrastriate most sever in right hemisphere (V2 and V3 involvement), but similar damage to left hemisphere also.

—

Some extension into white matter above upper calcarine sulcus bank

—

Possible damage to posterior MT (no unit response) but anterior still responded despite damage to STP and gray matter of MT. Anterior recordings used in data analysis.

—

Visual defect total for 60degrees

• f visual field.

RESULTS

¢ Overall Recording Quality (Computer and Auditory — MT unit RFs that feel within lesioned zone:

¢ MT unit response unlike Normal MT response- weak bursty

spontaneous activity (sounded “injured”)

¢ Single units hard to isolate

¢ Responsiveness (strong, weak, no response) — Following lesions, 66% of isolated units were still responsive

(for all lesion cases, i.e. no lesion-case dependent differences in responsiveness, x2 = 6, df =1, p>,2)

¢ However, only 5% “strong” (RFs within defect zone) ¢ Units with RFs outside lesion zone, gave strong responses, but not as

many as in normal MTs.

— All RF categories in lesion cases sig. differed to normal in

terms of proportion of strong, weak and no response (chi square tests, all p values < .02 ).

— No significant differences found between lesion groups in

terms of category responses (all p values > .2). Therefore amalgamated response data for all categories.

RESULTS

¢ What does this mean? — Taken as evidence to reject the idea that intact

striate cortex could be determining MT response

— No difference between response in total and partial

bilateral lesions.

RESULTS:

¢ Unilateral/bilateral comparison: ¢ Role of commisural/callosal

inputs

RESULTS: DIRECTION SELECTIVITY

RESULTS: UNILATERAL CASE

Question: Significance of RF in lesion zone compared to RF on Midline?

RESULTS: DIRECTION SELECTIVITY

¢ No difference between

normal/Striate cortex lesion

— Possible role for MT as

generating direction selectivity “de novo”

RESULTS: DIRECTION & TUNING SELECTIVITY

¢ No differences

RESULTS: OTHER FINDINGS

¢ Binocularity — 40 MT unit RF response did not differ substantially

between eyes

¢ Few responses better for either contra/ispsi but no strong

monocularity

¢ RF field size as function of eccentricity for single

units: Regression analysis (no sig difference between normal/lesion cases).

¢ Speed Selectivity: — Direction dependent

¢ Not explored further

EFFECTS OF STRIATE CORTEX COOLING

MATERIALS AND METHODS

RESULTS

DISCUSSION

¢ Afferent basis of residual visual responsiveness in

MT

— Dorsal LGN — MST and VIP — Spared portions of peripheral striate cortex — Tectopulvinar-MT path

DISCUSSION

¢ Contribution of striate cortex to response properties — Heterogeneous population of neurons dependent on striate

cortex for responsiveness to light

— Responsiveness not due to a recovery process — Effects outside the “lesion zone” — Callosal connections to responsiveness along the vertical

meridian representation in MT

— Marked shift or absence of selectivity — Direct or Indirect

ORIGIN OF DIRECTIONAL SELECTIVITY IN MT

¢ Striate cortex unnecessary for directionally

selective properties.

— Direction selectivity and tuning not different within/

• utside defect zone. (applies to control comparison

also)

— “Instrinsic circuitry” not striate dependent — Motter et al. (1987): MT generates direction

selectivity from nonselective inputs (Ascending and descending)

— BUT: doesn’t eliminate Striate role in directional

selectivity as 1/3 were no longer responding in the lesion cases. (Movshon and Newsome, 1984).

POSSIBLE ROLE FOR MT IN BLINDSIGHT

¢ Monkeys and humans can discern velocity and

direction.

¢ So far MT is the only area responsible for

generation of directional selectivity de novo in the absence of Striate input.

¢ Behavioral dysfunction: lowered gain can result

in inability to use information about velocity.
