A case for relaxed program logics Separation logic as a tool       for understanding and debugging the C/C++ concurrency model     Viktor Vafeiadis Max Planck Institute for Software Systems (MPI-SWS) January 15, 2014

Introduction Goal: Understand weak memory models Relaxed Tool: ❤❤❤❤❤❤ ✭ Concurrent program logics ✭✭✭✭✭✭ ❤ What have we achieved?? Verified some C11 programs Debugged the C11 weak memory model Viktor Vafeiadis A case for relaxed program logics 2/8

The C11 memory model Two types of locations: ordinary and atomic Races on ordinary accesses ❀ error A spectrum of atomic accesses: Relaxed ❀ no fence Consume reads ❀ no fence, but preserve deps Release writes ❀ no fence (x86); lwsync (PPC) Acquire reads ❀ no fence (x86); isync (PPC) Seq. consistent ❀ full memory fence Viktor Vafeiadis A case for relaxed program logics 3/8

� � � � Release-acquire synchronization: message passing Initially a = x = 0. a = 5 ; while ( x . load ( acq ) == 0 ); x . store ( release , 1 ); print ( a ); This will always print 5. Justification: W na ( a , 5 ) R acq ( x , 1 ) Release-acquire synchronization W rel ( x , 1 ) R na ( x , 5 ) Viktor Vafeiadis A case for relaxed program logics 4/8

Release-acquire synchronization: message passing Initially a = x = 0. Let J def = { 0 : emp , 1 : & a �→ 5 } . { & a �→ 0 ∗ W J ( x ) } { R J ( x ) } a = 5 ; while ( x . load ( acq ) == 0 ); { & a �→ 5 ∗ W J ( x ) } { & a �→ 5 } x . store ( release , 1 ); print ( a ); This will always print 5. PL consequences: Ownership transfer works! Viktor Vafeiadis A case for relaxed program logics 4/8

� � � � Dependency cycles Initially x = y = 0. if ( x . load ( rlx ) == 1 ) if ( y . load ( rlx ) == 1 ) y . store ( 1 , rlx ); x . store ( 1 , rlx ); C11 allows the outcome x = y = 1. Justification: R rlx ( x , 1 ) R rlx ( y , 1 ) Relaxed accesses don’t synchronize W rlx ( y , 1 ) W rlx ( x , 1 ) Viktor Vafeiadis A case for relaxed program logics 5/8

Dependency cycles Initially x = y = 0. if ( x . load ( rlx ) == 1 ) if ( y . load ( rlx ) == 1 ) y . store ( 1 , rlx ); x . store ( 1 , rlx ); C11 allows the outcome x = y = 1. What goes wrong: Non-relational invariants are unsound. x = 0 ∧ y = 0 The DRF-property does not hold. Viktor Vafeiadis A case for relaxed program logics 5/8

Dependency cycles Initially x = y = 0. if ( x . load ( rlx ) == 1 ) if ( y . load ( rlx ) == 1 ) y . store ( 1 , rlx ); x . store ( 1 , rlx ); C11 allows the outcome x = y = 1. How to fix this: Don’t use relaxed writes ∨ Disallow RW reoderings. Viktor Vafeiadis A case for relaxed program logics 5/8

� � � � Release-consume synchronization Initially a = x = 0. a = 5 ; t = x . load ( consume ); x . store ( release , & a ); if ( t � = 0 ) print ( ∗ t ); This program cannot crash nor print 0. Justification: W na ( a , 5 ) R con ( x , & a ) Release-consume synchronization W rel ( x , & a ) R na ( a , 5 ) Viktor Vafeiadis A case for relaxed program logics 6/8

Release-consume synchronization Initially a = x = 0. Let J ( t ) def = t = 0 ∨ t �→ 5. { & a �→ 0 ∗ W J ( x ) } { R J ( x ) } a = 5 ; t = x . load ( consume ); { & a �→ 5 ∗ W J ( x ) } { ✷ t ( t = 0 ∨ t �→ 5 ) } x . store ( release , & a ); if ( t � = 0 ) print ( ∗ t ); This program cannot crash nor print 0. PL consequences: Needs funny modality, but otherwise OK. Viktor Vafeiadis A case for relaxed program logics 6/8

Release-acquire too weak in the presence of consume Initially x = y = 0. while ( x . read ( consume ) � = 1 ); a = 1 ; y . store ( 1 , release ); x . store ( 1 , release ); ( ∗ ) while ( y . load ( acquire ) � = 1 ); ( ∗ ) a = 2 ; C11 deems this program racy. Only different thread rel-acq synchronize. What goes wrong in PL: On ownership transfers, we must prove that we don’t read from the same thread. Viktor Vafeiadis A case for relaxed program logics 7/8

Release-acquire too weak in the presence of consume Initially x = y = 0. while ( x . read ( consume ) � = 1 ); a = 1 ; y . store ( 1 , release ); x . store ( 1 , release ); ( ∗ ) while ( y . load ( acquire ) � = 1 ); ( ∗ ) a = 2 ; C11 deems this program racy. But, it is not racy: On x86-TSO, Power, ARM, and Itanium. Or if we move the ( ∗ ) lines to a new thread. So, drop the “different thread” restriction. Viktor Vafeiadis A case for relaxed program logics 7/8

Status report We know how to reason about: Release-acquire Consume reads (work in progress) C11 memory fences (work in progress) We found the following bugs in the model: Dependency cycles (also in [Batty et al. ’03]) Same thread rel-acq don’t synchronize Semantics of SC accesses odd and too weak. . . . . . when mixed with non-SC accesses Release sequences too strong Viktor Vafeiadis A case for relaxed program logics 8/8
